Vacuum Turbine Oil Purifier Oil Water Separator Industrial Oil filtration Machine
Applicable scope:
It is widely suitable for online processing of steam turbine, the gas turbine, the hydraulic turbine's oil in electric power,chemical industry, papermaking, metallurgy and so on to guarantee the unit adjusting and the normal work of the lubrication system.It used physical method remove the water, impurities and gas(acetylene, hydrogen, methane, etc), it will not change theoil components and performance.
Advantages:
1) turbine oil and water separator completely breaking the emulsion by adopt vacuum technology, molecular absorption, vacuum drying, automatically break emulsification technology.
2)Used unique ternary once dehydration method, not only remove large amounts of water from oil, but also remove trace moisture from oil, with high efficiency of dehydration and breaking the emulsion, it can let the serious turbid emulsion oil become transparent cleaning.
3)n be washed and repeatedly use, it have long life and need low cost. High-precision filter configuration can effectively remove fine particulate impurities from the oil.
4) Turbine oil and water separator using a combination of strong wind and water-cooled technology media condensing unit, condensing and except water from high temperature and high fever mixed gas, it improved the effective output power of the equipment, and extend the life of equipment.
5) Turbine oil and water separator have adopt low-load design in heater, ensured it can heat oil uniformly, can effectively prevent cracking and aging hazards of oil.
6)Advanced electrical systems and automatic infrared oil control system.
7) Turbine oil and water separator can unattended running with the turbine or other equipment, low noise, it correspond the high standard of world environmental protection requirements.
8)ZJC turbine oil filter with the automatic drainage device can drain continuously, it is easy operation and hommization.
9)If oil acid value is too high, you can choice BZ regeneration device to mach ZJC, reduce the acid value and dielectric loss, after process, acid value ≤0.03(mgKOH/g), let quality indicator meet the standard of "GB / T 7596-2008" the operation of turbine oil quality standards ". it can demulsification, dehydration, remove acid and impurities online, let the turbid emulsified turbine oil become clear and transparent.
Accessories:
(1)Used oil tank (2)Pre-filter (3) Heater (4)Water separator (5)Water receiver (6)Vacuum separation tank (7)Oil pump (8)Oil pump (9) Fine filter (10) Clean oil tank (11) Foam breaker (12)Radiator (13)Water receiver (14)Vacuum pump (15)Cooler (16)Water receiver (17) Exhaust port
Technical Specification of vacuum turbine oil purification
Item
| unit
| ZJC-10
| ZJC-20
| ZJC-30
| ZJC-50
| ZJC-75
| ZJC-100
| ZJC-150
| ZJC-200
|
|
Flow rate
| L/H
| 600
| 1200
| 1800
| 3000
| 4500
| 6000
| 9000
| 12000
|
|
Vacuum degree
| Mpa
| -0.06 ~ -0.096
|
|
Working pressure
| Mpa
| ≤0.3
|
|
Fault free
| H
| ≥4000
|
|
Continuous working time
| H
| ≥150
|
|
Working temperature
| °C
| 40 ~ 70
|
|
Heating power
| kW
| 15
| 18
| 30
| 45
| 60
| 72
| 72
| 84
|
|
Total Power
| kW
| 17
| 20
| 33
| 49
| 66
| 79
| 81
| 97
|
|
Diameter of inlet&outlet
| DN
| 25
| 25
| 25
| 32
| 42
| 42
| 50
| 50
|
|
weight
| Kg
| 500
| 530
| 570
| 780
| 800
| 960
| 1050
| 1550
|
|
Dimensions
| L
| mm
| 1300
| 1350
| 1450
| 1500
| 1500
| 1800
| 1800
| 1800
|
|
W
| mm
| 1000
| 1000
| 1100
| 1150
| 1000
| 1500
| 1650
| 1500
|
|
H
| mm
| 1450
| 1450
| 1500
| 1650
| 1750
| 1800
| 1900
| 2000
|
|
Oil index after treating by vacuum turbine oil purification
|
Water content
| 80ppm
|
Gas content
| ≤0.1%
|
cleanness
| ≤5µm(or as per requirement)
|
Demulsification Value
| ≤10 min
|
Details show
Machine Pictures:
