IR Night Vision.
Camera can be viewed via PC IE brower, PC LMS software, APP on smart cellphone, NVR and monitor.
Camera details.
| Camera |
| lmage Sensor | 8 Mega Pixel,HD SONY IMX415 Sensor |
| Min. lllumination | Color: 0.005Lux@F1.6; B/W: 0Lux with LED on |
| Lens | 3.6mm Standard; 2.8mm/6mm Optional |
| Electronic Shutter | AUTO, 1/25s ~ 1/100000s |
| LED Type | Infared |
| LED Distance | Up to 25m |
| Day/Night | Day/Night/Auto/Customize/Schedule |
| Image |
| Image Enhancement | BLC, HLC, 2D/3D DNR |
| WDR | 120dB Super WDR |
| Image Settings | Rotate, Mirror, Privacy Mask, Saturation, Brightness, Contrast, Sharpness, Gain, White Balance adjustable by client software or web browser |
| Defog | Yes |
| Video |
| Max.lmage Resolution | 8 Mega Pixel |
| Main Stream | 20FPS (3840*2160),25FPS(3072*2048), 30FPS (2592×1944,2304×1296), 60 FPS (1920×1080,1280×720) |
| Sub Stream | 30FPS (720×480,D1,VGA,640×360) |
| Video Compression | H.265+/H.265/H.264 video encode,Support Bitrate 0.1M~8Mpbs;Support Frame rate 1~30 Fps/s; |
| Video Bit Rate | 512Kbps - 6Mbps, VBR/CBR |
| Audio |
| Audio Standard | G.711-u/G.711-a |
| Built-in Mic | YES |
| Built-in Speaker | N/A |
| TF Card Slot | N/A |
| Interface |
| POE Port | RJ45 100mbps Network Port, IEEE802.3af PoE |
| Power Connector | DC12V (Spare) |
| Network |
| Network Storage | NFS /NAS /FTP(Photo) |
| Protocol | Supports network protocols such as HTTP/RTSP/DHCP/NTP/ONVIF/P2P/RTMP and multiple NVR docking protocols |
| P2P Cloud Service | Yes |
| System |
| Local Storage | MicroSD Card Slot Not Available |
| Motion Detection | Yes |
| Event Trigger Event Action | FTP Upload(Only Photo), SMTP Upload, SD Card Record,Alarm Server Center Upload |
| Intelligent Analysis | Humanoid Detection, Vehicle Detection |
| System Compatibility | Onvif (Profile S) |
| Web Client Language | English, Russian, German, Italian,Turkish, Polish, Korean,Japanese,Slovenian, Traditional Chinese, Simplified Chinese etc. |
| General |
| Protection Level | 304 Stainless Steel, IP67 (316 Stainless Steel Optional) |
| Working Temperature | -40ºC~60ºC (-40 °F to 140 °F) |
| Humidity Power Supply | 0~95%(Non-condensing) |
