Automatic 4 Cavity Pet Bottle Blowing Machine

Product Description

Automatic 4 Cavity Pet Bottle Blowing Machine
PET Bottle blowing machine is good at blowing PET bottle by 4cavity. It can blowing Max.2L volume bottle
1)Operation Step: The standard operation of automatic stretch blow molding machine includes four steps as follow
Step
1. Put the preform into preform container and the conveyer will take the preform to orientation units automatically.
Step
2. Load the preform at neck up to preform holder, and then preform is conveyed into baking tunnel.
Step
3. After heating, preform is conveyed into the blow station, then close the mold, stretch and blow under low pressure and high pressure, exhaust, open the mold.
Step
4. The finished bottle is taken off by automatic discharging system

2) Technical Parameter:

Items	General Information	BM-A4
Container	Machine Construction	One set Automatic Blow unit with Preform auto-loader
	Theoretical Output	3600-4000pcs/hr
	Max.container volume	1.5-2 L
	Max.neck diameter	50mm
	Max.container diameter	100mm
	Max.container height	340mm
	Number of cavity	4 Cavity
Electrical System	Total power	26kw
	Use Power	10kw
Air System	Working Pressure	1.0Mpa
	Low Pressure Consuming	1600L/min
	Blow Pressure	≤3.5Mpa
	High Pressure Consuming	2400L/min
Chiller Water	Opreating Pressure	0.8Mpa
	Temperature	10-12°C
	Flow Rate	45L/min
Machine Data	Machine Dimension	2.5*2.0*2.0m
	Machine Weight	2500kg
	Feeding Machine Dimension	2.0*1.0*2.0m
	Feeding Machine Weight	200kgs

---
