Plastic Injection Molding Machine Household Commodity Making Machine Plastic Products Machinery

Product Description

Horizontal Small Automatic Servo Energy Saving Plastic Fittings Injection Moulding Molding Machine
Product Parameters

Se-230T/IE Plastic Injection Molding Machine Information
Item		Unit		AA			A
Screw diameter		mm		40			45
Theoretical shot volume		cm³		283			358
Shot weight (PS)		g		257			326
Shot weight (PS)		oz		9.1			11.5
Length/Diameter ratio		L/D		22			22
Injection pressure		Bar		2531			2000
Injection rate		cm³/sec		200/350
Max.screw speed		rpm		300
Clamping force		KN		2300
Max.daylight		mm		810*760
Open stroke		mm		520
Space Between Tie-bars		mm		570*520
Min mould dimension		mm		220
Mould thickness range		mm		570
Ejector force		KN		80
Ejector stroke		mm		150
No.of ejector pins		unit		9
Motor power		KW		46
System pressure		MPa		175
Heater input power		KW		14
Oil filling capacity		L		200
Machine size		M		5.8*1.4*2.2
Net weight		KG		7800

SE/IV series machine advantages
Distributed architecture (n-tier);
TCP / lP efficient network connection,Internet remote control;
Synchronous cluster status browsing and parameter central control;Real-time heating curve to monitor barrel temperature changes.
Temperature and molding parameter statistics to assist in quality management.Expansion of the die storage space for mutual replication.
Scalability. providing interface with ERP.
Operator password rights management, recording of modification logs.Ease of operation and support for multiple languages.
Detailed Photos
