Jwell Small Automatic Blowing Molding Plastic Manufacturing Making Machinery Machine for Auto Parts, Automotive Urea Boxes, Toolboxes, Seats, Bumpers

Product Description

Product Parameters

Model	Unit	BM100
Max product volume	L	100
Dry cycle	Pc/h	360
Die head structure	type	Accumulating Type
Main screw diameter	mm	100
Max plasticizing capacity(PE)	kg/h	190
Driving motor	KW	55
Oil pump motor power(Servo)	KW	30
Clamping force	KN	600
Space between platen	mm	500-1300
Platen size W*H	mm	1020*1000
Heating power of die head	KW	30
Machine dimension L*W*H	m	5.5*2.5*4.0
Machine weight	T	16
Total power	Kw	135

Detailed Photos

Product Description
Product Description:
The JWZ-BM30/50/100/160 Blow Molding Machine is an advanced solution for manufacturing a wide range of automotive parts and plastic boxes, offering superior precision, versatility, and efficiency.
Key Features: Wide Application Range: Suitable for producing car urea boxes, toolboxes, automotive seats, air ducts, flow boards, bumpers, and car spoilers, catering to the diverse needs of the automotive industry. High Output Extrusion System: Equipped with a high-performance extrusion system and accumulating die head for consistent and efficient production. Customizable Platen and Size: Adjustable platen type and size to accommodate various product dimensions and ensure production flexibility. Optional Hydraulic Servo Control System: Enhances energy efficiency, precision, and operational stability. Material-Specific Options: Features the JW-DB single-station hydraulic screen-exchanger system to handle different material requirements effectively. Optional Bottom Sealing and Take-Out Robot: Provides automation options such as bottom sealing and robotic product removal to reduce labor costs and improve production efficiency. Applications: Car urea boxes for emission reduction systems. Toolboxes for automotive and industrial use. Plastic bumpers, air ducts, and flow boards for lightweight automotive components. Custom car spoilers and other plastic automotive parts designed for durability and performance. This blow molding machine offers a highly efficient and customizable production process, tailored to meet the demands of the automotive and industrial sectors for plastic parts and boxes with exceptional quality and reduced production costs.
