New Telescopic Small 40m 37m Tuck-Mounted Concrete Pump Sale in Peru

Product Description

New Telescopic Small 40m Concrete Pump Truck sale in peru
Product description: • Efficient and reliable pumping
• High configuration imported pump and motor ensure the reliability and stability of the hydraulic and electrical systems.
• The imported hydraulic oil filter ensures the cleanness of the hydraulic system and long service life of the hydraulic components.
• The adopted latest closed and variable hydraulic system of constant power has the full power takeoff, featuring 3MPa less in pressure loss, and saving the energy by 10%.
• The unique product in the hydraulic system-SN valve reduces the impact when changing the direction and settles the common issue of vibration of the pump, increasing the stability of the machine.
• The adopted S type change valve and new center pumping system feature higher efficiency, longer service life and more convenient maintenance.
• Keep the inclination of the optimized hopper in the best position, and adopt the automatic rotation device which could keep the hopper from blocking by the stone.
• Delivery pump, reducer piper and glasses board and cutting ring adopt the high-abrasive material, prolonging the service life of the wearing parts.
• Load sensing electro-hydraulic proportional control valve features excellent fine mobility and quick response.
• Intelligent experience
• X outrigger and one side operation.
• High and low pressure change freely.
Technical parameter Travel Pumping operation

Category	Item	Unit	Parameter
Chassis	Model		FM
	Max. speed	km/h	90.8
	Max. gradeability		34.70%
	Min. turning diameter	m	18.4
	Brake distance	m	≤7
	Wheelbase	mm	4900+1370
	Tread (front/rear)	mm	2019/1834
	Approach angle/departure angle	.	18/10
	Min. clearance	mm	270
	Tyre specification		12.00R20
Engine	Model		D13
	Output power	kw/(r/min)	294/1400-1800
	Max. torque	N.m/(r/min)	2000/1050-1400
	Displacement	l	12.8
	Emission Standard		Nation III GB
Others	Dimension (Length×Width×Height)	mm	11180×2500×3990
	Total vehicle weight	kg	32600
	Fuel tank capacity	l	410
	Fuel consumption per 100km	l/100km	40
Pumping system	Theoretical output(high pressure/low pressure)	m3/h	70/140
	Concrete pumping pressure(high pressure/low pressure)	Mpa	11.8/6.38
	Theoretical pumping times(high pressure/low pressure)	/min	15/27
	Max. diameter of pumping concrete aggregate		40
	Feeding height		1450
Placing boom	Pumping slump range		12-23
	Reach height		39.8
	Reach depth		27.9
	Slewing radius		35.8
	Slewing angle		370
	1st boom stretch angle		90
	2nd boom stretch angle		180
	3rd boom stretch angle		180
	4th boom stretch angle		240
	5th boom stretch angle		250
	Outrigger span	Overall outrigger span	7800
		Front outrigger transverse span	8350
		Rear outrigger transverse span	7200
Others	Dosing type		S valve
	Lubricating method		Automatic lubrication
	Controlling method		Manual/remote control
	Water tank capacity		600
	Max. pressure of water pump		2

Product image
