CNC Angle Line for Irrigation Pivots FINCM Communication Tower Cnc Shearing Punching Machine

Product Description

Product Description
APM2020 FINCM Tower Fabrication Plate CNC Automatic Making Drilling Punching Line 63*63*4mm~200*200*20mm
It is mainly used for customers to manufacture angle steel components, complete typing, punching, fixed length cutting on angle steel. Simple operation, high production efficiency.

Technical specification of APM2020C

Angle size	63mm×63mm×4mm ~ 200mm×200mm×20mm
Max. punching diameter	φ25.5mm(20mm thickness, Q345)
Nominal punching force	1100KN
Quantity of punching head per side	3
The quantity of punching row per side	arbitrariness
The quantity of character group	4 groups
Dimension of characters	14×10mm(10pcs)
Nominal Marking force	1030KN
Max. length of the raw angle	14m
Cutting mode	Single-blade shearing
Nominal Shearing force	4300KN
Quantity of CNC axes	3
Angle feeding Speed	40m/min, the efficiency is about 1000 holes/hour
Hydraulic station cooling method	water cooling

Angle feeding Speed: 40m/min, the effiency is about 1000 holes/hour
The finished angle conveyor is rotated to one side by pneumatic power. The max. Length of finished angle is 8 m.
There are four transverse conveyors which can infeed automatically.
Type of programming: Keyboard input, USB interface input, floppy disc input.
Working environment:
Working temperature: 0~ 40 degree
Power: Three phase four wire system
AC Voltage: 380V
Fluctuation of voltage: ± 10%
Frequency: 50 Hz
Main outsourcing components list of APM2020C:

Serial No.	Name	Brand	Country
1	AC Servo Motor	Panasonic	Japan
2	Orientation module	Mitsubishi	Japan
3	PLC	Mitsubishi	Japan
4	Unloading valve	ATOS/YUKEN	Italy/Taiwan
5	Relief valve	ATOS/YUKEN
6	Electro-hydraulic directional valve	ATOS/YUKEN
7	Solenoid reversing valve	ATOS/YUKEN
8	Single direction valve	ATOS/YUKEN
9	Valve plate	SMC/CKD	Japan
10	Air valve	SMC/CKD
11	Cylinder	SMC/CKD
12	Triple joint	SMC/CKD
13	Computer	LENOVO	China

Company Profile
Shandong FIN CNC MACHINE CO., LTD. is always focusing on our ultimate goal - to secure and increase our customer's productivity - has made us the leader in China market in the manufacture of machines for processing angle bar, beam channel profiles, steel plates, tubesheet and flanges, mainly serving for fabricating iron towers, steel structure, heat exchangers, boilers, bridges, and trucks.Strong R & D center with 30 engineers team, 24 years of experience from year 1997, 280 staff, plant area about 270,000 sqm., very harsh quality control of every component and the whole machine, about 40 million US dollars sales turnover per year.
FIN CNC machines' market share in China is around 70% and exported to 50+ countries across globe market. All top ranked tower manufacturers, steel structure fabricators and power station makers, bridge/railway manufacturers, truck makers are our clients.
Main products: CNC Angle Line, CNC Beam Drilling Sawing Machine, CNC Plate Drilling Machine, CNC Rail Processing Machine, CNC Tubesheet Flange Drilling Machine, Truck beam plate punching machine, etc..One measure of the outstanding quality of our machines is their longevity: many FIN machines have been in operation for more than 17 years! Many clients are continually placing repeated orders which verified well our machines' perfect quality and reliable performance.
The company drafted many China national standards for CNC angle line machine and CNC beam drilling sawing machine and CNC plate drilling machine.
Cooperative Supplier

Product Process Control

Customer Praise:

Sale Networks

Customer praise:
FAQ:
1. When can you arrange shipment?
For machines available in stock, the shipment can be arranged within 15 days after getting advance payment or L/C;
For machines non available in stock, the shipment can be arranged with 60 days after getting advance payment or L/C.
2. What can you do if my machines have problems?
1) We can send you free components if machines are in warranty period;
2) 24 hours service on line;
3) We can assign our engineers to serve you if you want.
3. Do you provide machine operation training?
Yes. We can send professional engineers to the working site for machine's installation, commissioning and operation training.
4. Which machine model shall I choose when I purchase from you?
Please share us your material size and your processing request, then we will recommend our machine most suitable and most cost effective for your work demand.
5. What's your machine's market share in China?
Our market share in China is about 70%+, and we've exported to 50+ countries across the globe market, since year 1998.

---
