Product Description
Product Description
Hydraulic High Speed Punch Press MachineModel: DP-30TonTonnage: 20T~100T available Specifications:ModelDP-20TDP-30TForce20T30TStroke100mm100mmMax die height100mm100mmTable size500*400mm500*400mmDescending speed100mm/sec100mm/secPressing speed30mm/sec30mm/secRebounding speed100mm/sec100mm/secOperating pressure21Mpa21MpaDie holeΦ30*60LΦ30*60LPower supplyAC380V three phaseAC380V three phasePower5HP(3.7KW)5HP(3.7KW)Oil capacity120L150LTotal weight850Kg1100KgDimension (L*W*H, mm)750*1130*2250750*1250*2300Note: Customerized requirements are available for design and producing.Features:1. Steel 4 POST frame body with high rigidity and free working space2. Mechanical positioning cylinder for high precision and accuracy production3. Water cooling system for lasting working time and durable performance4. Taiwan or Japan made essential parts and electric control system5. Perfect safety operating protection systemApplication:Multi functions for punching, pressing, cutting, bending, riveting, molding, assembling, etc.Applied to various industries like precision electronics, hardware, home appliance, telecommunications, automobiles, LED, etc. Want to increase your productivity but make cost lower ??Contact us for more automatic machinery solutions !!
>>
