| US$840.00-1,092.00 | 3 Sets (MOQ) |
| Specification | |
| Model No | KY400 |
| Swing over bed | 420mm |
| Distance between centers | 400mm |
| Taper of spind bore | MT3 |
| Spindle bore | 20mm |
| Range of spindle speeds | 160-1360rpm |
| Range of lingitudinal feed | 0.05-1.75mm/r |
| Range of inch threads | 8-120T.P.I |
| Tange of metric threads | 0.2-3mm |
| Travel of top slide | 80mm |
| Travel of cross slide | 120mm |
| Tailstock spindle travel | 70mm |
| Taper of tailstock quill | MT3 |
| Drilling &Milling | |
| Drill capacity | 15mm |
| Milling table | 150*200mm |
| End mill capacity | 20mm |
| Face mill capacity | 63mm |
| Spindle travel | 85mm |
| Taper in spindle bore | M.T.3 |
| Range of spindle speeds | 117 ~1300RPM |
| Optional accessories | |
| Four-jaw chuck | 1 set |
| Backplate | 1 pc |
| Follow rest | 1 pc |
| Steady rest | 1 pc |
| Face plate | 1 pc |
| Collet chuck | 1 set |
| Turning tools | 1 pc |
| Standard Accessories | |
| Drilling chuck | 1 pc |
| Toolbox & tools | 1 set |
