Product Details
Product Description
Product Description
Specifications
Hard chrome plated steel tubes , piston rod for hydraulic and pneumatic cylinder
CHROMED BARS
Hard chrome platedsteel bars Ck45 RANGE AND TOLERANCE.
- Diameter: 6-200 mm.
- Tolerance: ISO f-7, h7,
- Surface roughness: Ra. 0.2-0.8
- Hard chrome plated thickness: 0.012-0.015mm,0.015-0.02mm, >0.02mm
- HRC18-20
Induction hardened& hard chrome plated steel bars CK45RANGE AND TOLERANCE.
- Diameter: 6-200 mm.
- Tolerance: ISO f-7, h7, .
- Surface roughness: Ra. 0.2-0.8
- Hard chrome plated thickness: 0.012-0.015mm,0.015-0.02mm, >0.02mm
- HRC58-62
TECHNICAL PROPERTIES.
- Induction hardening depth: 1-5,4 mm.
Quenched and tempered& hard chrome plated steel bars CK45RANGE AND TOLERANCE.
- Diameter: 6-200 mm.
- Tolerance: ISO f-7, h7, .
- Surface roughness: Ra. 0.2-0.8
- Hard chrome plated thickness: 0.012-0.015mm,0.015-0.02mm, >0.02mm
- HB260-280
Hard chrome plated steel tubes RANGE.
- Outside diameter: 12-120 mm.
- Wall thickness: 2-12 mm.
TECHNICAL PROPERTIES.
- Hard chrome plated thickness: 0.012-0.015mm,0.015-0.02mm, >0.02mm
- Chrome layer hardness: 66-68 HRC.
- HRC18-20
- Steel grade: CK45.
TOLERANCES.
- Outside diameter: ISO f-7.
- Surface roughness: Ra.0.2-0.8
Induction hardened& Hard chrome plated steel tubes
RANGE. - Outside diameter: 12-120 mm.
- Wall thickness: 2-12 mm.
TECHNICAL PROPERTIES.
- Hard chrome plated thickness: 0.012-0.015mm,0.015-0.02mm, >0.02mm
- Chrome layer hardness: 66-68 HRC.
- HRC58-62
- Steel grade: CK45.
TOLERANCES.
- Outside diameter: ISO f-7.
- Surface roughness: Ra.0.2-0.8
Quenched and tempered&Hard chrome plated steel tubes RANGE. - Outside diameter: 12-120 mm.
- Wall thickness: 2-12 mm.
TECHNICAL PROPERTIES.
- Hard chrome plated thickness: 0.012-0.015mm,0.015-0.02mm, >0.02mm
- Chrome layer hardness: 66-68 HRC.
- HB260-280
- Steel grade: CK45.
TOLERANCES.
- Outside diameter: ISO f-7.
- Surface roughness: Ra.0.2-0.8
Hard chrome platedstainless steel bars RANGE AND TOLERANCE.
- Diameter: 20-200mm.
- Tolerance: ISO f-7.
- Stainless grades: AISI 431, AISI 316,AISI 304.
- Surface roughness: Ra. 0.2-0.8
TECHNICAL PROPERTIES.
- Hard chrome plated thickness: 0.012-0.015mm,0.015-0.02mm, >0.02mm
Hard chrome platedsteel bars 42CrMo4 RANGE AND TOLERANCE.
- Diameter: 8-150 mm.
- Tolerance: ISO f-7.
- Surface roughness: Ra. 0.2-0.8
- Hard chrome plated thickness: 0.012-0.015mm,0.015-0.02mm, >0.02mm
Induction hardened& chrome plated steel bars 42CrMo4 RANGE AND TOLERANCE.
- Diameter: 20-120 mm.
- Tolerance: ISO f-7.
- Surface roughness: Ra. 0.2-0.8
TECHNICAL PROPERTIES.
- Hard chrome plated thickness: 0.012-0.015mm,0.015-0.02mm, >0.02mm
- Induction hardening depth: 0.75-3.5 mm.
PRECISION TUBES
Honed Tubes
DESCRIPTION.
Honed tube. Inside tolerance H8.
RANGE.
- Inside diameter: 40-500 mm.
- Outside diameter: 45-1000mm.
- Wall thickness: 5-15 mm.
- Precision of Size: H9-H11
- Steel grade: ST-52. CK20C CK45, 25Mn,27SiMn
Roller burnishingfinish TubesDESCRIPTION.
skived and roller burnished tube. Insidetolerance H8.
RANGE.
- Inside diameter: 40-400 mm.
- Outside diameter: 45-1000mm.
- Wall thickness: 5-15 mm.
- Precision of Size: H9-H11
- Steel grade: ST-52. CK20C CK45, 25Mn,27SiMn
Stainless steeltubes
Alloy tubes
