| Max. temperature | 1200°C | 1400°C | 1700°C |
| Working temperature | 1100°C | 1300°C | 1600°C |
| Temperature accuracy | ±1°C | ±1°C | ±1°C |
| Thermocouple | K Type | S type | B type |
| Heating rate | 0 – 15°C / min | 0 – 15°C / min | 0 – 15°C / min |
| Temperature controller | Programmable PID controller Single program w/ 30 steps for Ramp & Soak Built-in auto tune function | ||
| Heating element | Fe-Cr-Al-Mo wire | U shape Sic heating elements | U shape Mosi2 heating elements |
| Furnace chamber | 1430°C ceramic fiber board | 1700°C ceramic fiber board | 1800°C ceramic fiber board |
| Door | Swing type door w/ screw locks | ||
| Gas | Nitrogen, Argon or any inert gas | ||
| Vacuum display | Dial type vacuum gauge | ||
| Vacuum pump | Rotary vacuum pump | ||
| Gas fittings | Stainless steel needle valves for Vacuum & Gas purge | ||
| Safety features | Over load protection Door safety limit switch keeps heater off when door is open | ||
| Inner Chamber (W x H x D) | Inner Chamber (W x H x D) | Volume |
| 100 x 100 x 100 mm | 4 x 4 x 4 Inch | 1 Liter |
| 150 x 150 x 200 mm | 6 x 6 x 8 Inch | 5 Liters |
| 200 x 200 x 300 mm | 8 x 8 x 12 Inch | 12 Liters |
| 300 x 300 x 400 mm | 12 x 12 x 16 Inch | 36 Liters |
