EVA Poe Three Layers Film Extrusion Machine Used for Solar Cellpanel Encapsulation

Product Description

Solar Cellpanel Encapsulation EVA POE Film Extrusion Line MachineEVA adhesive film production line features
1. the high degree of automation of this production, with the advantages of less production processes, less energy consumption and lower cost.
2. the developed stress relief device, which can effectively eliminate the residual stress generated during the stretching and production of the film online, thus solving the heat shrinkage problem of EVA film.
3. the special design of the cast molding part, which can well solve the problems of sticky rolls and peeling.
4. PLC human operator interface for electrical control, high degree of automation.
5. new type of automatic constant tension winding control system, accurate, stable and reliable tension measurement and control, improve work efficiency.
POE film production line features
It is very similar to EVA film equipment. EVA film production equipment can produce POE film normally with a little modification
1. salivation extruder adopts multi-machine co-extrusion POE single screw extrusion, screw barrel constant temperature circulating water cooling system, roller body part adopts double-sided embossing.
2. The cooling part adopts cooling roller and stress-relief cold bed to make the film run smoothly and set fully, ensuring the shrinkage rate is less than 3%.
3. The whole line adopts PLC automatic control to realize the operation of human-machine interface.
4. The production line is equipped with online quality monitoring and control system to ensure the product qualification rate.
5. Design micro tension winder.

Machine model	AF-160	AF-180	AF-180&AF-160	AF-180&AF-180
Raw Material	EVA,POE	EVA,POE	EVA,POE	EVA,POE
Film width	2600mm	2800mm	2800mm	2800mm
Film thickness	0.2-1mm	0.2-1mm	0.2-1mm	0.2-1mm
Line speed	10m/min	12m/min	15m/min	18m/min
