| Nominal diameter | mm (in.) | 620(24) |
| Nominal impedance | Ω | 8 |
| Minimum impedance | Ω | 7.9 |
| Program power (1) | W | 5000 |
| AES Power rating(2) | W | 2500 |
| Sensitivity (3) | dB | 97.2 |
| Frequency range | Hz | 28 ~ 1000 |
| Voice coil diameter | mm (in.) | 151(6) |
| Chassis material | Aluminium | |
| Magnet material | Neodymium | |
| Magnet dimensions (ODxIDxh) | mm | 146 x 60 x 10 |
| Coil material | SV | |
| Former material | Glass Fiber | |
| Xmax(4) | mm | 17.5 |
| Xmech(5) | mm | 28.5 |
| Gap height | mm | 17 |
| Voice coil Wingding height | mm | 44 |
| DC resistance | Re | Ohm | 3.6 |
| Resonance frequency | Fs | Hz | 28.2 |
| Moving mass | Mms | g | 523 |
| Compliance | Cms | mm/N | 0.06 |
| Force factor | BL | N/A | 29.8 |
| Mechanical Q-factor | Qms | 5.67 | |
| Electrical Q-factor | Qes | 0.39 | |
| Total Q-factor | Qts | 0.37 | |
| Equivalent air volume | Vas | I | 486 |
| Voice coil Inductance | Le | mH | 2.09 |
| Diaphragm area | Sd | cm² | 2376 |
| Reference efficiency | Eta 0 | % | 2.6 |
| Net weight | Kg | 25.7 |
| Multipack size (1) (W x D x H) | mm | 635 x 635 x 318 |
| Multipack weight | Kg | 28.8 |
