| US$100,000.00-190,000.00 | 1 Set (MOQ) |
| Manufacturer | Dynamic Energy | |
| Genset model | 500GFZ1-PWJ | |
| Engine model | G12V190ZLDK-2A | |
| Alternator model | 1FC6 454-6LA82-Z | |
| Breaker panel model | GCBP1 | |
| Field control panel | FCP1 | |
| Local control panel (Optional) | LCP1 | |
| Rated power | kW | 500 |
| Rated current | A | 902 |
| Rated voltage | V | 400 |
| Rated power factor | cosφ | 0.8 (lagging) |
| Frequency | HZ | 50 |
| Fuel gas consumption | MJ/(kW·h) | 10 |
| Lubricant consumption | g/(kW·h) | ≤0.8 |
| Electrical efficiency | % | 36 |
| Start-up method | DC 24V Electric motor | |
| Start-up control | Manual/Automatic | |
| Wiring method | 3 phase 3 line/3 phase 4 line | |
| Stable speed droop | % | ≤5 |
| Cooling method | Closed loop, with fan radiator | |
| Exhaust back pressure max. | 6 kPa | |
| Noise level | 105 db @ 1 meter away from the genset | |
| Genset vibration | ≤7.2mm/s | |
| Coupling between engine and alternator | Directly coupling (single shaft), with elastic coupler | |
| Dimension (L×B×H) | mm | 5433X1970X2700 |
| Weight | kg | 11200 |
Major component/system supplier & description: | ||
| Overall genset management | Dynamic patent TEM3 gas engine control system; + ComAp power control module; + Altronic/Motortech ignition system; + Heinzmann Pandaros/Orion speed governing system. | |
| Air/ fuel ratio control | Dynamic patent TEM3 gas engine control system | |
| Speed governing system (digital) | Heinzmann Pandaros or Heizmann Orion | |
| Ignition | Altronic digital ignition system or Motortech digital ignition system | |
| Intelligent circuit breaker | Changshu Switchgear or Tianshui 213 | |
