| Item | Specifications |
| Rated operating load | 3000Kg |
| Bucket capacity | 1.5~2.5m³ |
| Machine weight | 10900±200Kg |
| Dump clearance at maximum lift | 2770~3260Mm |
| Reach at maximum lift | 1010~1210mm |
| Wheel base | 2900mm |
| Tread | 1850mm |
| Height of hinge at maximum lift height | 3830mm |
| Working height(fully lifted) | 4870mm |
| Max.breakout force | 130Kn |
| Max.horse power | 95Kn |
| Hydraulic cycle time-raise | 5.5s |
| Total hydraulic cycle time | 10s |
| Min. turning radius over tyres | 5165mm |
| Articulation angle | 35±1 |
| Gradeability | 28° |
| Tyre size | 17.5-25-12PR |
| L×W×H | 7245×2482×3320mm |
| Engine Model | Weichai |
| Rated Power/Speed | 92/2300 kw/rpm |
