| Range | 30 mT | 300 mT | 3000 mT | |
| Resolution | 1 μT | 10 μT | 100 μT | |
| Measuring Range | 2 mT~3000mT[1] | |||
| Accuracy | Class 1 | ±1.0% | ||
| Class 2 | ±2.0% | |||
| Class 5 | ±2.0% ( 2 mT...1000 mT ),±5.0% ( 1000 mT...3000 mT ) | |||
| Temperature Coefficient | ± 0.1% / K | |||
| Zero Drift | ± 0.5 mT/h | |||
| Display Digit | 5 | |||
| Remark | [1]Calibration only covers 2.5T | |||
| Power Supply | 3 AA batteries or USB charging |
| Temperature Performance | Operating temperature: 0~50ºC; Storage temperature: -20°C~70°C |
| Humidity Performance | Operating humidity: 40%~80% R·H, non-condensing Storage humidity: <95% R·H, non-condensing |
| Weight | About 350 g |
| Interface | Hall probe input interface, USB interface |
| Overall Dimensions | 90mm(W) ×40 mm(D) × 165 mm(H) |
| Serial Number | Picture | Name | Specification | Quantity | Remark |
| 1 | TM1100 Hall probe | Radial | 1 | Standard Accessory | |
| 2 | TM1110 Hall probe | Axial | 1 | Optional | |
| Note: The users should indicate the probe in the order contract. | |||||
