Heavy-Duty EDM Wire Cutting Machine with Reliable Warranty Options

Product Description

Product model	DK7720	DK7735	DK7745F	DK7745	DK7750
Worktable stroke (mm)	420*270	710*480	920*540	810*570	950*650
Table travel (mm)	200*250	350*450	450*700	450*550	500*630
Machining height (mm)	200	480	480	480	600
Machining taper (mm)	6°,15°,30°/80
Cutting speed (m/min)	≥120
Surface roughness/finish(um)	≤2.5
Electrode wire diameter (mm)	0.1-0.2
Electrode wire fixed line speed (m/s)	11.5
Processing accuracy	According to GB7926-2005 standard≤0.02mm
Table movement pulse equivalent (mm)	0.001
Power supply	50Hz.380V
Machine tool power consumption (KVA)	<1.0
Workpiece weight (KG)	100	300	450	450	700
Main machine external dimensions (mm)	1160*810*1300	1240*1170*1400	1700*1600*1600	1600*1240*1400	1720*1680*1700

Product model	DK7750F	DK7763	DK7763F	DK7780	DK77100
Worktable stroke (mm)	1140*650	1140*750	1350*750	1350*985	1700*1170
Table travel (mm)	500*800	630*800	630*1000	800*1000	1000*1200
Machining height (mm)	400/600	600	600/800	600	1000
Machining taper (mm)	6°,15°,30°/80
Cutting speed (m/min)	≥120
Surface roughness/finish(um)	≤2.5
Electrode wire diameter (mm)	0.1-0.2
Electrode wire fixed line speed (m/s)	11.5
Processing accuracy	According to GB7926-2005 standard≤0.02mm
Table movement pulse equivalent (mm)	0.001
Power supply	50Hz.380V
Machine tool power consumption (KVA)	<1.0
Workpiece weight (KG)	700	1000	1000	2000	2600
Main machine external dimensions (mm)	2000*1900*1700	2100*1940*1780	2300*2200*1800	2600*2400*1800	3000*2800*2500

Company Profile
Jiangsu Sanlin Technology Equipment Co., Ltd. Jiangsu Sanlin Technology Equipment Co., Ltd. proudly stands as a beacon of innovation in the high-tech realm, specializing in the seamless fusion of production, research, and sales of cutting-edge CNC machinery and equipment. With a steadfast presence in the equipment industry spanning decades, we deliver excellence at every turn! Our core product lineup includes vertical machining centers, high-speed machines, gantry machining centers, drilling and tapping centers, engraving and milling machines, medium wire cutting machines, fast wire cutting machines, and much more. Renowned for their reliable quality and exquisite craftsmanship, our products have garnered the favor and admiration of customers worldwide. They play a pivotal role across key manufacturing sectors, including automotive, aerospace, national defense, medical food machinery, rail transit, and metal mold industries. Our commitment to excellence extends beyond borders, with products distributed nationwide and reaching Southeast Asia, Europe, Africa, and beyond. At Sanlin, our pursuit of perfection is unwavering, and we continuously strive to deliver unparalleled products to our users. We warmly invite customers and friends to engage in fruitful collaboration!
FAQ
A: As a premier manufacturer, we extend a warm welcome for you to visit our factory and witness the expertise behind our offerings. A: To choose the ideal model, start by matching the worktable travel and cutting thickness to your workpiece's dimensions. Next, ensure the precision and roughness align with your standards; our TRS series machines excel with superior precision and finish. A: Absolutely, please specify the voltage you require, and we will accommodate your needs. A: We offer free replacement of damaged parts within the warranty period and at cost price afterward. Should any issues arise, we swiftly provide solutions through instructional videos or other means.Q: Are you a manufacturer or distributor? Q: How do I choose the right machine for my needs? Q: Our country operates on three-phase 220V (or single-phase 220V, or other voltages), but the machine's voltage is three-phase 380V. Can you adjust the voltage? Q: What kind of after-sales service do you offer?

---
