Model Number | SS-XLJ-550 |
Machine Size | 12000mm(L)*5000mm(W)*4500mm(H) |
Car size | No limit(L)*4200mm(W)*4700mm(H) |
Installation size | 12000mm(L)*5000mm(W)*5300mm(H) |
Applicable vehicle | Buses, buses and various types of sanitation vehicles |
Power Supply | 380VAC, three-phase five-wire |
Car wash method | High-pressure brushless channel type, PLC computer control |
Water Consumption | 300L/car |
Flushing pressure | 2.5-3kg/cm2 |
Car wash time | 50-60 cars/hour |
Total power | 30KW |
weight | 4T |
Sludge removal | Sedimentation tank filtration |
Frame material | Steel plate, square tube, bending frame, hot-dip galvanizing treatment, resin powder spraying |
Electric and gas circuit configuration | Japan's Mitsubishi PLC controller, Schneider Electric parts, American Banner sensor |
Machine configuration | Fully automatic intelligent operating system |
High pressure cleaning configuration | 2 pcs high-pressure cleaning water pumps |
nozzles | stainless steel 304 rotating nozzle and fixed nozzle |
