SS316 314 Falling Film Vacuum Evaporator for Waste Water Treatment

Product Description

https://wztaikang.en.made-in-china.com/product-list-1.html

Sr.No	Evaporation Rate(kg/h)	Feed Density	Heat Area	Condenser	Cooling Water	Weight(KG)	Power	Material
1	1000	1-3%	34,21,21	22	30T/H	7000	31.5KW	316L
2	1477	1.5%	52,33,33	34	45T/H	9000	42.5KW	316L
3	1490	15%	54,33,33	34	45T/H	9000	55KW	316L
4	1500	2-5%	51,32,32	33	45T/H	9000	35.5KW	316L
5	1584	11%	53,33,33	34	45T/H	8000		304
6	1615	5-6%	57,35,35	36	48T/H	7500	40.5KW	TA2,316L

SS316 314 Falling Film Vacuum Evaporator for Waste Water Treatment
Specification
1. Falling Film Evaporator can be designed to be 1~6 effect, as client' request.
2. Material available: stainless steel 304, 316L, Titanium.
3. It needs only 330KG steam to evaporator 1000KG water, which is very energy saving.
4. Detailed civil foundation drawing can be offered.
5. Our technician will go to client' plant for installation and commissioning.
Application:
It's applicable for dairy products, pharmacy, glucose, starch,chemical industry, xylose, citric acid, ammonium sulfate, biological engineering, environmental engineering and waste liquid recovery and treatement. etc.
Equipment structure:
It consists of (first-effect, second-effect, third-effect)separators and evaporators and preheaters,condenser and vaccum pump, feeding pump,circulation pump, discharge pump, condensed water pump and system pipe fittings, etc. Equiped wit CIP spraying cleaning ball, vacuum gauge, thermometer,pressure gauge,and so on.
Equipment characteristics:
1. Material: SUS304 or SUS316L;
2.Full closed process, fast and low temperature evaporation;
3.Inside pipes are mirror polishing seamless sanitary pipes, so material is not easy to paste on the pipe all, it's easy for cleaning;
4.Low steam consumption: 1kg steam can evaporte 3.5kg water;
5.Low evaporation temperature:part of secondary steam can be inhaled into single-effect heater through spray type hot pressure pump, this would make full use of the heat and the evaporation temperature is low.
6.Large concentration ratio: adopt falling film evaporation, which make the material liquid with larger viscosity be easy to flow and evaporate, hard to scale, short cocentration time, the concentration ratio can reach to 1:5.
7.This equipment can realize automatic production, intellectual system management, which is in conformity with GMP standard.
8.Can be desinged into different technological process according to the different characteristics of the materials , also can according to different users' requirements equip with automaticl control system.
Working principle
Compress secondary steam by using steam centrifugal compressor or other steam compression device to make sure its physical properties meet with the requirements for heating steam ; evaporation that uses it as heating steam only requires fresh steam supply when the machine is started. After entering normal operation, there is no need to supply new steam and no (or very little) secondary steam needs condensation. Therefore MVR evaporation substantially cuts down steam demand but consumes more power.

Quantity(Sets)	1 - 10	>10
Est. Time(days)	60	To be negotiated

Company Profile

FAQ
1.How long can I receive your reply after I send my inquiry?
We will reply you within 12 hours on workday.
2.Are you a manufacturer or a commercial company?
We are a manufacturer, and we have a foreign trade department, we market our own products.
3.What products can you provide?
We mainly produce evaporators, tank systems,valve.....
4.What are the application fields of your products?
Our products are mainly used on food, beverage,diary, chemical & pharmaceutical industry.
5.Can you provide custom products?
Yes, custom products are our main products. We can develop and manufacture products according to customer's drawing, sample or description.
6.How many employees do you have?
We have over 100 employees, including several technicians and engineers.
8.How do you ensure your product quality?
We conduct inspections in every production procedure, and for finished products, we will take 100% inspection depend on international standards according to customer's requirements.
9.Payment?
We will confirm the payment with you when quoting, like FOB, CIF, CNF or others.We accept 30% deposit, balance before shipment. T/T is the main payment, and L/C is acceptable as well.

---
