Aoasis ATS126-D1 Three Phase Energy Meter

Product Description

Product Description
The meter is suitable for three-phase four-wire system/three-phase three-wire system/two-phase three-wire system. The meter is designed to measure AC active energy. lt is a long-life instrument with high stability, high overload capacity, low power consumption, small size and other advantages.
Basic Function
· Mechanical step register or LCD display· Bi-directional total active energy measurement, reverse active energy measure in the total active energy· Pulse LED indicates working of meter, Passive pulse output with optical coupling isolation· Loss phase LED indication, Reverse connection LED indication· For LCD display type meter, Energy data can store in memory chip more than 15 years after power off· 35mm din rail installation
Technical Data

Rate Voltage AC	ATS126-D1 three phase four wire 3x120/208V, 3x220/380V,3 x230/400V 3x240/415V
Working Voltage AC	0.8~1.2Un
Rate Current	5A/CT, 1.5(6)A, 5(60)A, 10(100)A, or other as required
Frequency	50Hz or 60Hz
Connection Mode	CT Type or Direct Type
Display	Mechanical step register or LCD
Accuracy Class	1.0
Power Consumption	<0.5W/5VA/each phase
Start Current	0.004lb
AC Voltage Withstand	4000V/25mA for 60s
lmpulse Voltage	6kV 1.2 μs waveform
IP Grade	IP20
Constant	400~6400 imp/kWh
Pulse Output	Passive pulse, pulse width is 80 ± 5 ms
Executive Standard	DIN 43880, IEC62053-21, IEC62052-11
Work Temperature	-30°C ~70°C
Outline Dimension	126*93*65mm

Product Catalog
Company Profile
FAQ
Q1. What's the payment term? A. We accept TT,30% deposit and 70% balance before shipping. Q2. How's the delivery time ? A. We depend on different products and different quantities. Generally, it takes about 3-15 days. If the quantity is very large, we need to negotiate. Q3. Tell me the standard of package? A. Normally are cartons, but also we can pack it according to your requirement. Q4.Could you offer Form A or C/O ? A. It's totally not a problem. We can prepare relative documents to forgin affairs office or other office to apply for thiscertificate. Q5.Would you accept to use our logo ? A.If you have good quantity,it absolute no problem to do OEM

---
