| Negotiable | 30 unit (MOQ) |
| MODEL | 264(260) | 284(280) | 304(300) | 354(350) | 404(400) | 504 |
| TRACTOR PARAMETER | ||||||
| Drive form | 4*4(4*2) | 4*4 | ||||
| Outline size | 3350*1500*1860 mm | 3500L | ||||
| Structure weight | 1210-1380 KG | 1500 | ||||
| Front wheel base(mm) | 970.1200.1300 adjustable | 970.1200.1300 adjustable | ||||
| Back wheel base (mm) | 1000.1200.1300 adjustable | 1000.1200.1300 adjustable | ||||
| Spread of axles (mm) | 1750 | 1750 | ||||
| Minimum Ground Clearance(mm) | 330(340) | 330 | ||||
| DIESEL ENGINE | 2 cylinder JD | 2 or 3 cylinder JD/LD | 3 cylinder JD/CC | 4 cylinder JD/CC/YD | 4 cylinder JD/LD | 4 cylinder JD/LD |
| Type | In-line, water cooled, 4-stroke, natural aspirated | |||||
| Model | JD2100 | JD2102/LD385 | JD390/LD390/CC390 | JDM490/LD4L22/YD485 | JDM490/LD | LD4L100BT |
| Rated power(KW) | 19.1 | 20.58 | 22.06 | 25.7 | 29.4 | 36.8 |
| Rated speed(r/min) | 2300/2400 | |||||
| Aspiration | Natural aspirated | |||||
| Displacement(L) | 3.432 | 3.432 | 3.432 | 3.432 | 3.5 | 3.6 |
| Clutch | Single Disc, Dry, Dual-Stage, constant meshed | |||||
| TRANSMISSION | ||||||
| Gear box | 2 axis 4*(2+1) gear group type | |||||
| Shifting | Meshing sleeve gear shifting | |||||
| Differential Gears | Double planet wheels, closed type | |||||
| Differential lock | Pin type | |||||
| Final transmission | Planet wheel type | |||||
| PTO SHAFT | ||||||
| Type | Independent and synchronous PTO. | |||||
| Speeds | R/min | 540/720 or 540/1000 | ||||
| Three point linkage | Category II | |||||
| Control | Position | |||||
| Hydraulic output adaptor | Size: M16X1.5, quantity: 1; Output flow rate: 20L/min | |||||
