50mm 90mm Random Packing Polypropylene Plastic Hollow PP Plastic Pall Ring

Product Description

Product Description
Product Description50mm 90mm Random Packing Polypropylene Plastic Hollow PP Plastic Pall RingPP high flow ring,the strong structure provides high mechanical stability with high void fraction. The low weight and themechanical stability enable us to use high packed heights without intermediate packing supports. High capacity of gas and liquid flow rates, very low wall flow and low sensitivity to pollution.If High flow rings replace conventional tower packing, then the flow rates in existent columns can be considerably increased or the energy consumption can be significantely reduced.Specification50mm 90mm Random Packing Polypropylene Plastic Hollow PP Plastic Pall Ring specification Model /Size 16×16×1.0mm25×25×1.2mm38×38×1.4mm50×50×1.5mm76×76×2.6mmMaterial PPPPPPPPPPNumber per volume (n/m3)180000490001360063001830Surface area(m2/m3)27421315110072Void Volume (%)9091919292Dry PackingFactor (m-1)37628520013092Other MaterialPall ring packing is divided into three materials: metals, ceramics, plastics and the like.Wherein the metal material: 304, 316, 316L, carbon steel, 201 and so on.The plastic material: PP, RPP, CPVC, PVDF, PVC, ETC.Temperature60°C~150°C.Details Images50mm 90mm Random Packing Polypropylene Plastic Hollow PP Plastic Pall Ring picture details Product features 50mm 90mm Random Packing Polypropylene Plastic Hollow PP Plastic Pall Ring feature * High free volume * Low pressure drop * Low mass transfer unit height * High flooding point * Uniform gas-liquid contact * Small specific gravity * High mass transferPacking & DeliveryRecommend ProductsContact

---
