Fire Sprinkler 1/2 68 Degree Sidewall Type for Fire Fighting

Product Description

Product Description
FIRE SPRINKLER HEAD SIDEWALL TYPE
Fire sprinkler is a nozzle that use to spray water to the fire.
It is installed at the end of water pipe.
It can sense the heat by a specific glass bulb then open automatically to allow water spray out to extinguish the fire.
Product Feature
1) Sprinkler material:brass
2) Plate material: stainless steel
3) Surface colour: chrome
4) Sensing element: glass bulb
5) Thread:BSP R1/2" DN15
6) Type:Sidewall
7) Temperature:68ºC
8) Working pressure : 1.6MPa/ 16bar / 235psi
9) Glass bulb: standard respond
10)K factor:5.6gpm/psi½(80 lpm/bar½);
11}Weight: pendent 53.5g
Application
Hotels,hospitals, shopping mall, factory, schools and so on.

Product Parameters

Norminal Diameter	Connection Thread	Flow rate	Temperature
DN15	R1/2"	80±4	57/68/79/93/141°
DN20	R3/4"	115±6	57/68/79/93/141°
