2m Patent Protected Plastic Water Drainage Dimpled Membrane Extrusion Machine

Product Description

Plastic Water Drainage Dimpled Membrane Extrusion Machine
Junsheng Brand machines have passed CE certificate and exported to over 20 countries, like Turkey, Poland, Russia, Romania, Germany, Kosovo, etc.
Machine guarantee is 2 years and we offer Turn-key project.
Brief Introuction of Junsheng Waterproof Sheet Machine:
- Convex wall thickness of the circular convex on the drainage panel is well-proportioned.
- Compression strength is 50% higher than similar product, which solves the problem.
- Power saving 30%.
- Higher output
- Same forming roller, with changing different dimples, different sizes will be got.
- With changing mould, round and square shape.
- Drainage board thickness range is 0.5-5.5mm, width up to 5000mm.
Main Technical Specification of Junsheng Waterproof Sheet Machine:

Model		PSB-2000	PSB-3000	PSB-4000	PSB-5000
Screw dia.	mm	135	150	180	150×2
L/D ratio	L/D	30:1	30:1	30:1	30:1
Product width	mm	2000	3000	4000	5000
Product height	mm	8, 10, 12, 15, 18, 20, 25, 30, 35, 40
Output	Kg/h	400	500	700	1000
Line speed	m/min	2-6
Installed capacity	KW	252	320	410	550
Power consumption	KW	132	160	220	300
Dimensions (L×W×H)	m	22×4×2.8	22×5×2.8	22×6×2.8	23×6×2.8
Total weight	T	16	20	28	35

More Photos:

---
