Three Layer Co-Extrusion Rotary Die Film Blowing Machine

Product Description

This machine is applied to manufacturing printed or uncolored T-shirt bags made of HDPE, LDPE roll film. It adopts double stepping (servo) motor fixed length, and the feeding, sealing, cutting, punching holes and transporting are completed only in one process. It is of high degree of automation and good economic results. Product Parameters
Applications:
Three-layer plastic coextrusion blow molding composite film units are developed by us according to the market requirements. In the design structure, advanced levels of similar products at home and aboard are absorbed. They are applicable to LDPE, HDPE, LLDPE, MLLDPE and PA packaging films. Such films can be widely used in light and heavy packages such as various kinds of fresh fruit, meat wares, pickles, fresh milk and liquid drinks because they are quite able to provide barriers, preserve moisture, and resist damp, rain, wind, frosting and oil, and isolate oxygen.
Main technical parameters:

Model	3SJ-G1000	3SJ-G1200	3SJ-G1500
Diameter of screw	55×2 60×1	60×2 65×1	65×2 70×1
Length-diameter ratio	28:1/30:1	28:1/30:1	28:1/30:1
Speed of screw	15-150r/min	15-150r/min	15-150r/min
Power of main motor	15Kw×2 18.5Kw×1	18.5Kw×2 22Kw×1	22Kw×2 30Kw×1
Output of a single extruder	50kg/h	80kg/h	100kg/h
Specification of die orifice	150 φ200	200 φ250×1	250 300×1
Film thickness	0.01-0.10mm	0.01-0.10mm	0.01-0.10mm
Max. lay-flat width of film	1000mm	1200mm	1500mm
Total capacity of electric appliance	76Kw	88Kw	102Kw
Overall dimensions:	6600×4100×5000mm	6800×4300×6000mm	7000×4800×7500mm
Machine weight	4T	5T	6T

Detailed Photos
Packaging & Shipping
Certifications

---
