Bq Type Impregnated Diamond Core Bits

Product Description

Product Description Impregnated diamond bit
The impregnated diamond bits are the most commonly useful bits in the mineral exploration industry, as they have the widest range of application. The carefully selected grades of high-quality synthetic diamond are distributed in the depth of impregnated bit's matrix series. The matrix layer of the crown contains a uniform distribution of these crystals that are embedded in a powdered metal bond. The matrix of our impregnated bits is designed to expose new diamonds to the bits cutting face as wear occurs. Fast penetration rate is maintained as a result of this action.
The matrix layer of the impregnated diamond core drill bits crown contains a uniform distribution of these crystal diamonds that are embedded in a powdered metal bond. The main technical parameters of impregnated diamond core drill bits are diamond specifications, like type, size, concentration and grade, as well as matrix hardness type and crown shapes, which are selected according to the hardness and abrasiveness of the formation to be drilled. If user can make rational selections according to the rock formations, then they can get satisfied drilling performance on various formations with different hardness. 1: the impregnated diamond core bits feature drilling speed and long service life
2: the design of more cutting edges makes drilling progress smoother
3: during the manufacturing process, the diamond is free erosion and fully utilized
4: the impregnated diamond core drill bits are of various configurations and meet various needs of local conditions
5: it offers the most widely-used bit matrices as well
6: with various specifications, our series matrix range provide an easy selection and reliable foundation for your drilling needs
Size: our bits are available in all standard drilling sizes. Also, non-standard sized bits can be produced according to requirements from clients
Matrix height: 6mm-8mm (most cost-effective), 8mm-10mm (long service life), 12mm-16mm (super service life)
Bit Crown Profiles: "W" profile, "Flat" profile, "Semi-round" profile, "Cross" profile, "Gear profile"
Waterways: Various waterways are available for diamond impregnated bits. Differing waterways allow for better flushing in various ground conditions and drilling systems.
Threads: standard Q threads as well as thread types required by clients are available Size Avaiable 1. A-Gauge Core Bits: AQ, AQ-RSG, AWG(AX), AWM, AWT, LTK48 2. B-Gauge Core Bits: BQ, BQ-RSG, BQ-2.400, BQ3, BWG(BX), BWM, BWT, LTK60, TBW 3. N-Gauge Core Bits: NQ, NQ-3.032, NQ2, NQ2-RSG, NQ3/NQTT, NQ3-RSG, NQ3-3.032, NMLC, NWG(NX), NWM, NWT, TNW 4. H-Gauge Core Bits: NQ, HQ-RSG, HQ-3.830, HQ-3.895, HQ3/HQTT, HQ3-RSG, HQ3-3.380, HQ3-3.895, HMLC, HWF-Long, HWF-Short, HWG(HX), HWT 5. P- Gauge Core Bits: PQ, PQ3, PWF-Long, PWF-Short 6. S- Gauge Core Bits: SWF-Long, SWF-Short 7. U- Gauge Core Bits: UWF-Long, UWF-Short 8. Z- Gauge Core Bits: ZWF-Long, ZWF-Short 9. T, TT, T2 &TB Series Metric Core Bits: T36, TT46, T2-46, TB56, TT56, T2-56, T2-66, T2-76, T2-76 coreline, T2-86, T2-86 coreline, T2-101, T2-101 coreline 10. T6 Series Metric Core Bits: T6-76, T6-86, T6-101, T6-116, T6-131, T6-146 11. T6S Series Metric Core Bits: T6S-76, T6S-86, T6S-101, T6S-116, T6S-131, T6S-146 12. B Series(ISO3552-1) Metric Core Bits: B36, B46, B56, B65, B76, B86, B101, B116, B131, B146 13. Chinese Standard Metric Core Bits for Single Tube Core Barrels: φ 36, φ 46, φ 56, φ 59, φ 75, φ 91, φ 110, φ 130, φ 160, φ 170, φ 219, φ 275 14. Chinese Standard Metric Core Bits for Double Tube Core Barrels: φ 56, φ 59, φ 75, φ 91 15. Chinese Standard Metric Core Bits for Wireline Core Barrels: φ 59, φ 75, φ 91 We can manufacture all kinds of I diamond core drill bits and reaming shells according to customer's special requirement. .

FAQ Q:Are you manufacturer?
Yes, we are factory with more than 20 years of manufacturing experience.
Q:What is your terms of payment?
A: T/T 30% as deposit, and 70% before delivery. Before shipping, we will send all detail pictures and packing list. L/C
Q:What is the warranty of our machine?
A:Our main machine for 1 year warranty, And we provide videos for machine install and operation, Provide spare parts service on time.
Q: How long is your delivery time?
A: Generally it is 5-10 days if in stock. or it is 15-20 days if the goods are not in stock according to quantity.
Q:How do you make our business long-term and good relationship?
A:We keep good quality and competitive price to ensure our customers benefits;

Construct site pictures
Related product
Packaging & Shipping

---
