Th-8203s Universal Material Testing Machine

Product Description

TH-8203S Adhesive Peel Strength Testing Machine is used to test various materials (both finished and semi-finished products ) of tensile strength ,compression and elongation ,stripping force ,tear strength ,bending strength ,compression ,etc.
Technical parameter:

Item	TH-8203S	TH-8203A	TH-8203
Capacity	10N,20N,50N,100N,200N,500N,1kN,2kN
Value resolution	1/±500000		1/±200000
Deformation resolution	0.0001mm	0.001mm	0.001mm
Displacement resolution	0.0005mm	0.001mm	0.001mm
Displacement speed range	0.001-500mm/min	1.0-500mm/min(adjust)	1.0-500mm/min(adjust)
Effective space	700mm
Dimension	450*400*1250mm
Weight	60kg

Specifications:
Capacity choice: 5,10,20,50,100,200,500,1000, 2000N optional
Stroke: 700mm(excluding clamp)
Range of speed: 0.001~500mm/min
Effective testing space: 150mm
Weight 70kg: Accuracy ±0.5%
Force Resolution: 1/±500,000
Dimension: (W×D×H)450×400×1250mm
Motor: AC Servo Motor and control drive system
Optional Accessories: Computer, printer, system operation manual
Characteristics:
1. Adhesive Peel Strength Test Machine structure is made of the paint-coated aluminum blanking plate. The interior is used the high-accuracy, low-resistance and zero clearance of two ball screw and oriented pole which improve loading efficiency and structure rigidity.

2. Adhesive Peel Strength Testing Machine Use AC Servo Motor and control drive system which ensure high efficiency, steady transmission and low noise. The accuracy of speed can be controlled in ±0.5%.

3. Adhesive Peel Strength Testing Machine That Using the business computer as the main control machine plus the special testing software of our company can conduct all of testing parameter, work state, collecting data& analysis, result display and printing output.
Certificate:
Fixtures :
Packaging & Delivery
Packaging Details:
1.Inner package:Dust-proof plastic bag
2.Outer package:Standard export wooden case with pallet
3.Suitable for international transport through shipping by sea, by air or any other delivery method.
(Note:We can provide special packages according to buyer's requirements.)
4.Packing size:
5.Gross weight:
Delivery Detail:15 working days
Wooden box (as attachment)
About US:
Established in 2006, Suzhou Tophung Machinery Equipment Co., Ltd. is a professional manufacturer of Material Quality Testing Machines, who integrates R&D, production, sales and after-sales service. For more than ten years, the company has been committed to providing its customers with excellent Testing Machines and professional quality testing solutions for material testing, structural testing and finished product testing. Tophung products are widely used in those industries such as metal materials, new composite materials, solar photovoltaic new energy, wire and cable, auto parts, plastic products and other products.
Our Products:
Our Team:
Suzhou Tophung Machinery Equipment Co., Ltd. is responsible for the development of national scientific and technological basic equipment, focusing on research and development of scientific testing equipment. Up to now, the company has obtained 32 various authorized patents, CMC manufacturing license, ISO quality management system certification, and EU CE Certification. The main series of Testing Machines have obtained national patents and have independent intellectual property rights.
Exhibition
The 13th Shanghai International adhesive tape, protective film and optical film exhibition & the 13th Shanghai international high functional film exhibition (apfe) was held in the National Convention and Exhibition Center (Shanghai Hongqiao) from May 24 to 26, 2017, as the world's largest and influential annual gathering of adhesive tape and film. The exhibition area is planned to be 26800 square meters, with 1350 international standard booths. It is expected that more than 600 domestic and foreign brand exhibitors will be gathered. The grand scale lineup and international influence will become the greatest ever!
With a professional team, rigorous management, excellent product quality, and the enterprise spirit of "pursuing excellence, keep improving ", Suzhou Tophung Machinery Equipment Co., Ltd. insists on using corporate culture to enhance the core competitiveness of the enterprise, which helps the enterprise to establish a good social image in the way of development, and focus on creating an excellent national brand of Chinese Testing Machines.
Our Services:
If you face any problems in future during testing process we promise we will give you a reply within 48 hours and solution provide within 3 working days. We can offer operation video and English operation muanual. We can provide video-conference. If customers require on-site service, the transport and travel expense shall be borne by customer.1. Pre-service --24 Hours online service for your consult. --Help choose right model,and a series of service,person,advise.2. Middle service --Give you best offer --Provide discount for many sets order --Do customer's request: --Choose payment term you convienent. --Promptly production and delivery,inform you in time. --Can provide invoice value as you like to decrease your tax. 3. After sale service --1 year warranty service and all life maintenance. --Technical Egineer are avalible for oversea trainning. --Free change for some parts --Remote control technical consult --Maintenance plan4. Commitment:We will sign a letter of commitment while we sign the contract, which will improve your confidence to us.5. Good Packaging:Simulation Animatronic Customer Triceratops are covered with air bubble film before put them into the wooden case, which not only has good shock absorption, impact resistance, heat sealing and also has the advantages of nontoxic, odorless, moisture corrosion, good transparency etc
FAQ: Q:Are your company a trading one or a factory?A:Factory + trade (integration),More than 12 years focusing on test equipment field,6 years exporting experience.Q:After an order is placed, when to deliver?A:Generally about 10-25days, If we have inventory, we can arrange shipment within 3 days.Please be aware that our production lead times depend on specific items and item quantities.Q:What about the warranty with after - sales services?A:The testing machine is guaranteed for 12 months by HAIDA,we can help you to repairyour problem controller freely,even it's not from our factory. After the warranty, the professional after-sale service team will provide perfect technical support and help guests solve problems encountered while using our product, handles guest problems and complaints in a professional and timely.Q:What about the product' services and quality?A:Each equiopment must be carried out 100% quality examination and test when shipping and delivery goods. Product use training, each of our product provide video training to show you how to install & operate. We can arrange engineer to train the operation of equipment to customer's company when you need. products are widely recognized and trusted by users.A :Considerate Service Different countries plugs, manually change the-voltage from 110V to 220V, insurance indicator.Q: Can your products be customized?A: Yes, our product can be customized according to your parameters.
Contact information:
Dear customer,
If you need our testing machines, please send us inquiry without any hesitate !
-------------
Suzhou Tophung machinery equipment Co., Ltd.
Contact information
Hi this is Cherry. We are willing to help you on quality control tests. Looking forward to hearing from you. Please Send your inquiry Details in the below for our quotation, Click "Send" Now!


Dear customer,
if you need our testing machines, please send us inquiry without any hesitate ! Best Regards
Sharnia Li
Suzhou Tophung Machinery Equipment Co., Ltd.

http://tophung.en.made-in-china.com
Add:No. 8 Liuzhuang Rd, Mudu Town, Wuzhong District, Suzhou, Jiangsu, China 210151

---
