Swimming Pool Water Treatment, Suspended Solids and Sand Removal, Quartz Sand Filters

Product Description

Model	Tank specifications	Import and export specifications	Single tank flow	Work pressure
LF-SYS500	ф500*2150	DN50	2t/h	10kg
LF-SYS600	ф600*2250	DN50	3t/h	10kg
LF-SYS800	ф800*2450	DN65	5t/h	10kg
LF-SYS1000	ф1000*2550	DN65	8t/h	10kg
LF-SYS1200	ф1200*2650	DN65	12t/h	10kg
LF-SYS1500	ф1500*2850	DN80	18t/h	10kg
LF-SYS1600	ф1600*2950	DN80	20t/h	10kg
LF-SYS1800	ф1800*3050	DN100	25t/h	10kg
LF-SYS2000	ф2000*3150	DN100	30t/h	10kg
LF-SYS2200	ф2200*3300	DN125	40t/h	10kg
LF-SYS2400	ф2400*3400	DN125	50t/h	10kg
LF-SYS2500	ф2500*3450	DN125	60t/h	10kg
LF-SYS2600	ф2600*3450	DN150	70t/h	10kg
LF-SYS2800	ф2800*3600	DN150	80t/h	10kg
LF-SYS3000	ф3000*3900	DN219	100t/h	10kg
LF-SYS3200	ф3200*4500	DN219	120t/h	10kg
LF-SYS3400	ф3400*4600	DN250	150t/h	10kg
LF-SYS3600	ф3600*4650	DN250	180t/h	10kg

FAQ
1. Question: What industrial water filters do you mainly produce?A: Our factory mainly produces self-cleaning filters, security filters, bag filters, sand and gravel filters, fiber ball filters, dirt removers, backwash filters, etc., which are mainly used in industrial water treatment equipment. In addition, we also produce accessories for filters such as filter screens, filter cartridges, filter bags, and other filter elements.2. Question: What is the maximum processing capacity of the Shallow Sand Filter? A: This filter can achieve a maximum processing capacity of 1000m ³/h.3. Which type of filter can be used to reduce turbidity?A: You can use our quartz sand filter, which uses quartz sand as the filtering medium to filter water with high turbidity through a certain thickness of granular or non granular quartz sand under a certain pressure, effectively intercepting and removing suspended solids, organic matter, colloidal particles, microorganisms, chlorine, odors, and some heavy metal ions in the water.4. Question: Where is your factory located? How can I get there?A: Our factory is located in Xinxiang City, Henan Province. It takes 2 hours by high-speed rail from Beijing or fly to Zhejiang Airport, and then we will pick up your team. We warmly welcome you to visit us anytime.5. Q: What is the installation method of the filter?A: Skid loading and transportation. Just connect the inlet/outlet flange and drain it.6. Question: Can you customize products?Of course, if you can provide us with detailed specifications or drawings. Our mission is to inspire customers with ideas about our products and provide satisfactory solutions.

---
