Rubber Strip Cutting Equipment/Full-Automatic Slitting Cutters/Rubber Strips Cutting Machine

Product Description

Rubber strip cutting equipment/full-automatic slitting cutters/rubber strips cutting machine

Technical parameters of rubber slitting machine

1. Slitting Machine Description
Slitting machine for cutting a variety of infinite rubber, paper and plastic leather belt. cloth foam PVC And other non-metallic sheet with a certain hardness plate. Adopt the hob cutting style, size can be adjusted, the speed is steady, uniform,not deviate. Different requirements of different materials requires specialized design, matching the appropriate tool. The machine uses a foot control, hands completely relieved, to facilitate easier and safer operation

2. Structure specifications
Our rubber slitting machine have 2 structures, one is knife framework type, you can freely adjust the cutting strip width, its range is 20mm-1200mm.
Another is bushing fixed type, the strip width size is fixed.

3. Technical parameters

Model: FTJ1200

Working width:1200mm

Cutting speed: 8~10m/min

Cutting sheet thickness: max 25mm

Cutting strips width: to 1200mm (adjustable)

Cutting length: unlimited

Standard quantity of blades: 10pcs

Rpm of blade: 60r/min

Motor power: 1.5KW

weight: 650KG

Dimensions: 1720×1000×1330mm


Power supply: according to customer's actual conditions

---
