330t Servo Injection Molding Machine

Product Description

China servo injection molding machine.

A. modulus of capacitance: The position, size, and maximum allowable modulus of capacitance and minimum closure thickness of the injection molding machine guide pillar (Green column).standard injection molding machine manufacturer

B .nozzle parameters: spherical diameter of the nozzle, nozzle aperture, nozzle outer diameter, maximum nozzle extension length, positioning aperture.standard injection machine. C. code mold parameters: code mold hole, slot size.ce standard injection molding machine. D .Ejection mechanism: The position of the ejection point and the diameter of the ejector rod, and if necessary, the ejection force and ejection stroke are also provided.
E. Mold opening stroke and maximum opening distance.plastic injection machine

Technical Parameters	Model UP-330T
Injection Unit	A	B	C
Screw diameter (mm)	65	70	75
Shot Volume (cm3)	1077	1250	1458
Injection weight (g)	970	1143	1312
injection pressure (Mpa)	197	170	148
Screw speed (rmp)
Clamping Unit
Clamping force (KN)	3300
Open stroke (mm)	635
Max Mold height (mm)	670
Min Mold height (mm)	250
Space between tie bars(mm)	670*670
Ejector force (KN)	80
Ejector stroke (mm)	160
Others
Pump pressure (Mpa)	16
Motor/driving power (KW)	37(36.7)
Heating power (KW)	24.4
Machine dimension (M)	7.2*1.9*2.35
Machine weight (T)	12.8
Oiltank cubage (L)	600

FAQ
1: Are you a trading company or a manufactory?
We are a manufactory, we supply the factory price with good
quality, welcome to visit !
2:Do you have QC or any safety standards for your plastic injection molding machine?
yes,we have established a highly strict quality control department to guanrantee good quality.
3:Why choose our plastic injection molding machine?
High quality with competitive price
4::How about quality control in your factory?
"Quality is first, Customers are friends".
5:Can you help us with the shipment of this machine ?
Yes , with honor ,we have our special shipment company which
already cooperate

---
