Product Details
Product Description
Product Description
H2601 wireless pressure sensor
1) Specifications reference our datasheet.
2) Supply power offerred by HW01 wireless router
3) Continue monitor level changes on tank or others
4) Micropower and long time stability
5) Submersible on bottom of tank or rivers/lake/well/container/sea…
6) Application: Logger level data information and send data to wireless router.
7) Power Supply: 3.6 V DC (Li-Battery)
8)Communication frequency band:2.405GHz~2.480GHz
9) Communication rate:38400bps
10)The transmission distance: 400 meters
11)Water proof grade: IP67
12)Data update rate: 1 times/sec (min) or by customized.
13)Battery power supply time 2 months (data update rate for three minutes)
3. HW02 Wireless Network Coordinator
1) Power Supply: 5V/1A adapter (recharger)
2) Data transmission: Zigbee wireless protocol
3) Wireless rate: fixed 250K
4) Communication frequency band:2.405GHz~2.480GHz
5) Interface: RS-232
6)Communication rate:38400bps
7) Transmission distance: 400 meters
8)Average current:≤70mA
9) Peak current:≤250mA
4. PC Software
1) English or Chinese language display version optional.
2) Display pressure data for each one transmitters
3) Integration control functions for Coal mine underground water control, urban drainage control, industrial waste water level control, the river lake monitoring, pipeline pressure control, Building water supply control systems etc.
>>
