REF601 REF610 REF610C ABB Control panel touch screen (in stock)

Product Details

Product Description

Product Description
REF601 REF610 REF610C ABB Control panel touch screen (in stock)
REF601 REF610 REF610C ABB Control panel touch screen (in stock)
Our Email: 2235954483@qq.com
contact number:13313705507
contacts：HE
The CI854/CI854A/CI854B is powered from the processor unit via the CEX-Bus
and requires therefore no additional external power source.
Use the following procedure to install the CI854/CI854A/CI854B/TP854:
1. Mount the unit onto the DIN-rail, see Mounting AC 800M Units onto DIN-Rail
on page 71 and Installing the PM85x/PM86x/TP830 Processor Unit in Single
Configuration on page 84.
2. Install a connector on the PROFIBUS DP cable. A connector with a switchable
built-in bus termination is recommended. Connect the cable screen to the metal
case of the connector to ground the screen via CI854/CI854A/CI854B. Connect
the data cable wire A to the terminal PIN8 (RxD/TxD-N) and the data cable
wire B to the terminal PIN3 (RxD/TxD-P). If the data transfer cable has data
wires with red and green insulation, then the following assignment should be
used:
Data cable wire A: green
Data cable wire B: red
3. Connect the cable shield for both lines to functional ground, for example by
using a grounding clamp.
4. Connect the PROFIBUS DP cable to one of the connectors PROFIBUS A or
PROFIBUS B on the baseplate. For support of Line Redundancy connect a
second PROFIBUS DP cable to the other contact.
5. If the CI854/CI854A/CI854B is at the end of the PROFIBUS DP cable, switch
the bus termination ON. Otherwise leave the bus termination switched OFF.
The following applies for CI854A/CI854B:
6. If the CI854A/CI854B is installed in a redundant configuration connect the
PROFIBUS DP cable to primary and backup module. Do it like described in
Figure 44 on page 126. Switch the termination ON for the interface on primary
or backup module that is at the end of the line.

---
