US$13,000.00-18,000.00
|
1 Set
(MOQ)
|
Basic Info.
Machine Usage
Cutting Plywood
Machine Motor Power
40.4 Kw
Transport Package
Plastic Film
Specification
4 feet by 8 feet
Production Capacity
10 Sets/Month
Product Description
Detailed Photos
Product Description
TECHNICAL PARAMETERS
| Model | DDS48 |
| Main frame material | 100*120 mm square steel tube |
| Cutting size | 1220*2440 mm |
| Cutting thickness | maximum 60 mm |
| Diagonal tolerance | less than 1 mm |
| Straightness tolerance | less than 0.5 mm |
| Saw head | Casting, fine finishing |
| Bearings | NSK (Japan brand) |
| Voltage standard | 380V, 50HZ |
| Pneumatic element | AKS |
| PLC brand | SIMENS |
| Touch screen displayer | SIMENS |
| Main elctrical parts | CHINT |
| Inverter | DELTA |
| Feeding speed | 0-30 meters per minute, adjustable |
| Line speed | 5315 meters per second |
| Saw blade speed | 6800 turns per minute |
| Electrical control panel | dust-free and powder painting |
| Total Motor power 40.4 KW | main saw blade head 7.5 KW, 4 pieces |
| small saw blade head 1.1KW, 4 pieces |
| lift table motor 3 KW, 1 piece |
| working table motor 1.5 KW, 2 pieces |
| The first saw guide rail | 30 mm diameter , Six arrises guide |
| The second saw guide rail | 30 mm diameter , cylindrical guide |
| Saw blade | 4 big saw blade, 4 small saw blade (Germany BAK brand) |
| Gross weight | 4800 KGS (fixed with screw and can load with 1*40HC container) |
Company Profile
WHAT WE DO
SERVICES
Packaging & Shipping
Certifications
FAQ
FAQ
1. Rich experience and professional design
We have abundant experience in plywood production, also has many years exporting experience. Each equipment location,passage will be designed reasonably to meet safety production.
2. Competitive price
ZHONGHE has own factory,with the same configuration,the price is competitive.And we are familiar with the Chinese market,our suppliers provide high-quality cost-effective accessories.
3. Timely after-sale service
We have over 15 skilled technicians offer after-sale service, will be sent to the customer's factory to assist in the installation and debugging of the flooring production line until it runs well,and asked for quick responses to customer questions.
4. One-stop solution
ZHONGHE provideS one-stop service, including market analysis and professional technical consultation, raw materials ,equipment installation, personnel training.Professional after-salesservice team,renovation of old equipment,make turnkey projects.
5. Quality control
Strict quality control of equipment in production and before leaving the factory, and a complete quality management system for purchased parts.Customers are always welcome to make videos or come to the factory to know the production status.
>>
