| US$1,000.00-10,000.00 | 1 Piece (MOQ) |
| Tank Optional Configuration |
| The body of Magnetic Stirring Tank can chose sterile air filter, thermometer(Digital display or Dial type), PH meter, pressure gauge, steam sterilization hole, sight glasses, sanitary manhole, liquid in-outlet, CIP Universal rotating cleaning ball, liquidometer and Liquid level control system(Bearing module, non-contact ultrasonic, static pressure transmitting device) and so on, also can configure as customers' requirement. |
| Feature |
| • Volume:100L~5000L and multiple specification, also can design and manufacture according to customers' requirement. • Jacket can pass steam (or hot water), can also pass the cooling water. Jacket has disk tubular, full jacketed and Maitreya plate. Jacketed outside covered with insulation, thermal insulation material for rock wool (warm) or PU (cold). • The connection adopts Tri-clamp, the tanks' inner use 304 or 316L. The inner surface mirror polishing Ra≤0.28μm~0.6μm, outer surface can polishing, wire drawing and sandblasting according to customers' requirement. • Using bottom magnetic stirring, special designed stirring paddle, The best revolving speed range should be 20r/min~400 r/min, Can be suitable for mixing different medium. |
| Application | |
| • Can be a Storage Tank, mixing tank, temporary Storage Tank, mixing tank, etc., Used in liquid materials' mixing and storage such as food, dairy products, fruit juice beverage, pharmaceutical, chemical and biological engineering. | |
| Design parameter | |
| Design pressure | Barrel according to customers' requirement(0.02MPa~0.8MPa) Jacket according to customers' requirement(0.02MPa~0.5MPa) |
| Design temperature | Barrel and Jacket according to customers' requirement(0ºC~160ºC) |
| Material | |
| Liner | 304,316L |
| Jacket | 304 |
| Insulation | Rock wool (keep warm) PU (cold insulation) |
| Feet | 304 |
| Connection | |
| In-outlet | Quick open, Flange |
| Surface Finish | |
| Finish Type | Mechanical polishing, electrolytic polishing, sand blasting, pickling |
| Polishing precision | Inner wall 0.28μm,outer wall 0.6μm |
