| Items | parameters |
| Frequency range | 500-2700Mhz |
| Output Power | 50 W |
| Gain | 50 dB |
| Gain Flatness | ±1.5dB |
| IMD3 | -26dBc |
| Output I.C.P | +53.0dBm |
| Operation Mode | Class A |
| Impedance | 50Ω |
| Input Return Loss | 9.5dB (min.) / VSWR : 2.0 (max.) |
| Output Return Loss | 9.5dB (min.) / VSWR : 2.0 (max.) |
| AC Supply Input | AC100V±15% / 1φ, 50 / 60Hz, 300VA |
| Maximum RF Input Power | +3.0dBm |
| Cooling | Forced Air Cooling |
| Protection Circuits | Over Temperature Protection Power Supply Voltage Protection |
| RF Input | N Female |
| RF Output | N Femal |
| Operating Temperature | 0ºC to +40ºC |
| Storage Temperature | -15ºC to +65ºC |
