Machine to Make Corn Flour Mill Machine (6FYF)

Product Description

Features of flour mill machine
1.Roller mills are manufactured precisely and controlled by pneumatic mode.It can make better grinding effect comparing with other ordinary mills.
2.Complete sets of wheat flour processing machine adopt various configuration modes for different choices.There are streamlined design, reasonable layout, beautiful performance.It can be installed on a steel frame structure or in a building structure.
3.The flour processing machine is with advanced technical process and flexible adjustment.It can produce grade flour and special flour etc.
4.Perfect after-sales service is also supplied for complete set of flour processing machine.
Mainly produce grade 1 flour, grade 2 flour and other kinds of special flour for food.It can produce co-production grade flours.
This equipment has lower investment, quick return, high effect, lower energy consumption, high efficiency.
One flour mill plant have three section:

Cleaning section	Cleaning out the middle and small impurity from grain.E.G., dust, stone, magnetic material, grain was bitten by insent and so on.Includes beating, screening, destoner, magnetic separator and dampening.This section is to prepare fpr milling part and to protect the machinery as well.
Milling section	Mill:Mill the grain to break the integrity by the roller moving Sifter:To separate the four, bran and other by-product, also separate large size and small size to ensure flour quality.
Packing section	Weighting and packing the flour into bags.

Model Item	6FYF-22
Production capacity (T/24h)	22
Milling Techniques and main machines	4break-3reduction-1bran brushing(4-6F1820 roller mill, 4-round sieve, 1-83 double section plansifter,1-bran brusher,1-blower)
Cleaning Techniques	1 sifting-2 scouring-2 destoning-2 magnetic separating-1 washing-1 air separating (high speed vibrating sieve, scourer, magnetic separator, low pressure blower,washing machine)
Products and extraction rate (%)	Grade 2 flour: 70%~75%, Standard flour: 78%~83%
Flour quality	Better than GB1355-88 (National standard of China)
Power required (kW)	58.85
Size of workshop: (L×W×H, m)	16×5.5×4.2

Model Item	6FYF-40
Production capacity (T/24h)	40
Milling Techniques and main machines	4break-4reduction-1bran brushing(1-6F2240 roller mill, 7-6F2235 roller mill,4-round sieve, 2-83 double section plansifter,1-conveyor,1-bran brusher,1-vibrating rated feeder)
Cleaning Techniques	1 sifting-2 scouring-2 destoning-2 magnetic separating-1 washing-1 air separating (high efficiency vibrating sieve, scourer, bucket elevator, destoner, low pressure blower,washing machine)
Products and extraction rate (%)	Grade 1 flour: 60%~68%, Standard flour: 78%~83%
Flour quality	Better than GB1355-88 (National standard of China)
Power required (kW)	96.31
Size of workshop: (L×W×H, m)	24×7×6.8

Model Item	6FYF-50
Production capacity (T/24h)	50
Milling Techniques and main machines	4break-6reduction-1scratch-2bran brushing(4-6F2240 roller mill, 6-6F2235 roller mill,3-83 double section plansifter,5-round sieve,2-bran brusher,1-vibrating rated feeder,1-conveyor)
Cleaning Techniques	1 sifting-2 scouring-2 destoning-2 magnetic separating-1 washing-1 air separating(high efficiency vibrating sieve, scourer, bucket elevator, destoner, low pressure blower,washing machine)
Products and extraction rate (%)	Grade 1 flour: 60%~68%, Standard flour: 78%~83%
Flour quality	Better than GB1355-88 (National standard of China)
Power required (kW)	112.91
Size of workshop: (L×W×H, m)	28×7×7

Our company is a supplier of wheat flour milling plants, maize flour milling plants, grain cleaning machinery and steel silo with well-equipped testing equipment and strong technical force.
With a wide range, good quality, reasonable prices and stylish designs, our products are extensively used in food, grain storage, feed industries and other industries.
Our products are widely recognized and trusted by users and can meet continuously developing economic and social needs.
We welcome new and old customers from all walks of life to contact us for future business relationships and achieving mutual success!

---
