| US$150,000.00-800,000.00 | 1 Piece (MOQ) |
| Project | Numerical | Remarks | |
| Working performance parameters | Maximum rated total lifting weight kg | 50000 | |
| Maximum lifting moment of basic boom kN.m | 1764 | ||
| Maximum lifting moment of the longest main boom kN.m | 1182 | ||
| Max. lifting height of basic arm m | 12.7 | ||
| Maximum lifting height of main boom m | 46 | No consideration of boom deformation | |
| Maximum lifting height of jib m | 61.5 | ||
| Working speed | Maximum speed of single rope (main winch) m/min | 140 | No load, fourth level |
| Maximum speed of single rope (auxiliary winch) m/min | 140 | No load, fourth level | |
| Boom lifting time s | 43 | ||
| Boom extension time s | 90 | ||
| Rotation speed r/min | 0 to 2.6 | ||
| Driving parameters | Maximum service altitude m | 2000 | |
| Maximum driving speed km/h | 80 | ||
| Maximum gradeability% | 50 | ||
| Minimum turning diameter m | ≤ 24 | ||
| Minimum ground clearance mm | 272 | ||
| Fuel consumption per hundred kilometers L | 39 | ||
| Quality parameters | Self-weight in driving state (total mass) kg | 40700 | |
| Vehicle curb weight kg | 40570 | ||
| Front axle load kg | 14700 | ||
| Rear axle load kg | 26000 | ||
| Dimension | Overall dimension (length×width ×height) mm | 14380 × 2800 × 3760 | |
| Longitudinal distance of leg m | 6.3 | ||
| Leg transverse distance m | 8.0 (full extension),5.26 (half extension) | ||
| Tail turning radius mm | 4280 | ||
| Main arm length m | 11.7-45.5 | ||
