| Model | CX23LEDRF (S1/S2) |
| Body | Aluminum die-casting metal frame, Protective covering |
| Optical System | Infifi nity optical system |
| Illumination System | Built-in transmitted illumination system, LED Power Consumption 0.5 W (nominal values) |
| Focusing | Stage height movement (coarse movement stroke: 15 mm), coarse adjustment limit stopper, Torque adjustment for coarse adjustment knob, Fine focus knob (minimum adjustment gradations: 2.5 µm) |
| Revolving Nosepiece | Fixed quadruple nosepiece |
| Stage | Wire movement mechanical fifi xed stage Traveling range: 76 mm (X) x 30 mm (Y), Specimen holder, Specimen position scale |
| Observation Tube | 30º inclined binocular tube Interpupillary distance adjustment range: 48 - 75 mm, Eyepoint adjustment: 370.0 - 432.9 mm |
| Objectives | Plan achromat, anti-fungus 4x NA: 0.10 W.D.: 27.8 mm 10x NA: 0.25 W.D.: 8.0 mm 40x NA: 0.65 W.D.: 0.6 mm 100xOil NA: 1.25 W.D.: 0.13 mm (CX23LEDRFS1 only) |
| Eyepiece (10x) | Field Number (FN): 20 (anti-fungus) |
| Optional Accessories | Reflfl ection mirror (CH20-MM), 15x eyepiece (WHSZ15X-H: FN 12, anti-fungus), Dedicated wooden case, Eyepiece micrometer, Darkfifi eld stop (CH2-DS+CH2-FH) |
| Weight | Approx. 5.9 kg |
| Rated Voltage/Electric Current | AC 100-240 V 50/60 Hz 0.4 A |
| Power Consumption | Less than 2 W |
