Adhesive sticker / label roll to sheet cutting machine with two unwinding shaft

Product Description

Product Description
Adhesive sticker / label roll to sheet cutting machine with two unwinding shaft
Functional Characteristics:
1.DELTA servo motor pull the material,high precision.
2.MITSUBISHI PLC with touch screen to set any length,quantity,speed.
3.3 inch inflatable shaft for unwinding.
4.14mm thickness steel wall make machine run stable.
5.Pulling roller coat thick PU rubber and won't scratch the material.
6.Polished and anodized aluminum guiding roller,very smooth and never harm the material.
7.Long service life of the SKD11 cutting blade and cut the sheet edge smoothly.
8.Panasonic photocell to track the printed mark for precise cutting.
9.Other standard machine:360mm,600mm,800mm,1000mm,1400mm.
Purpose:
This machine can cut flexible materials from roll to sheet,such as plastic,paper,label,film,foam,aluminum foil etc.
Technical Data:
Model
DP-500
Max Feeding Width ( mm )
500
Max unwind roll diameter(mm )
600
Max unwind roll weight(kg)40
Unwind shaft diameter3 inch
Cut 320mm speed ( times/minute )About 70
PLCMITSUBISHI
Servo Motor Servo Driver DELTA
Precision ( mm )±0.10
Power
380V 50HZ

Electrical listing:
Touch Screen
KUNLUNTONGTAI
Made in China
Programmable Controller
MITSUBISHI
Made in Japan
Servo Driver
Delta
Made in Taiwan
Servo Motor
Delta
Made in Taiwan
Motor of cutting knife
SHENLI
Made in China
AC Contactor
CHNT
Made in China
Solid State Relay 20A
GOLD ELECTRICAL CONTROL
Made in China

With two unwinding shaft:
