| Product Name | socket weld flange, socket flange welding, socket weld flange welding,socket flange |
| Size | 1/2"-60" |
| Class | 150#, 300#,400 #,600#,900#, 1500# ,2500 #,PN6, PN10, PN16, PN25, PN40, PN64 etc. |
| Standard | ANSI B16.5, ANSI B16.47,ANSI B16.36, ANSI B16.48, ANSI B16.47 Series A & B, MSS SP44, AWWA, etc. |
| Material | Carbon Steel: ASTM A105/A105N, A350 LF1, A350 LF2 CL1/CL2, A350 LF3 CL1/CL2, A694 F42, A694 F46, A694 F48, A694 F50, A694 F52, A694 F56, A694 F60, A694 F65, A694 F70, A516-60, A516-65, A516-70, C22.8 etc. |
| Stainless Steel: ASTM A182 F202, A182 F304/304L/304H, A182 F316/316L, F316H, F316TI, F310, F321, F904L etc. |
| Duplex stainless steel: A182 F51,A182 F53, A182 F55 etc. |
| Alloy Steel : ASTM A182 F1, ASTM A182 F5, ASTM A182 F9, ASTM A182 F11, ASTM A182 F22, ASTM A182 F91 etc. |
| Nickel alloy: inconel600, inconel625, inconel690, incoloy800, incoly 825, incoly 800H, C22, C-276, Monel400, Alloy20 etc. |
| Application | Oil Field, Offshore, Water System, Shipbuilding, Natural Gas, Electric Power, Pipe Projects, etc. |
| Flange Face Type | Flate Face (FF), Raised Face (RF), Ring Type Joint (RTJ) |
Good strength and plasticity: with high strength and good plasticity and toughness.
Cheap: Compared with other types of flanges, the price is relatively low.
Easy connection: bolt connection, easy to align when assembling.
Good sealing performance: Through the fastening of the bolt, the flange gasket is squeezed to form a seal.
Poor corrosion resistance: After a period of use, corrosion may occur, resulting in medium leakage.
High welding requirements: relatively high welding technology requirements, such as poor welding, easy to cause weld cracks.
Not suitable for high pressure and high temperature environment: Due to its structural characteristics, flat welded flange is not suitable for high pressure and temperature occasions.
When using carbon steel flat welded flange, it is necessary to select the appropriate material and specifications according to the specific working conditions and medium conditions, and design, manufacture and installation in strict accordance with the relevant standards and specifications to ensure its performance and safety and reliability.(YNMT)ยท
