Welcome to visit

YORNEW Desktop CNC Lathe Machine

Product Details

Product Details

Product Description

Product Description
The YORNEW Desktop CNC Milling Machine is the proven desktop machining solution perfect for prototyping in aluminum, other soft metals, plastics, and other materials. Iterate fast with a CNC machine right at your desk.
With additional course content, how-to projects, and a robust support team, the YORNEW Tools Desktop CNC Machine is a great STEAM tool to skill up on CNC machining. It’s an excellent addition to any shop, lab, classroom, studio, or makerspace.
Features
(1).Automatic 4 positions tool post.
(2).KY 980Tc Turning CNC System
(3). ARM 9 CPU+FPGA,Support B macro function,PLC function,Mutil-language library function.
(4).Lathe CNC machine tools based entirely on the design and manufacture, reflects the structural integrity of facilitate future design ideas.
(5). The standard spec includes MPG hand wheel.
(6). USB and RS232 port, DNC function of USB.
(7). Control speed of G code.
(8). Selection of high -quality casting materials,more compact.
(9). A collection of double-nut ball screw, bearings and couplings with high precision positioning, while adding an automatic oil lubrication system, to protect your machine precision, extended service life.
(10). 220VAC or 110VAC single-phase AC power supply.
(11). Safety electrical components of high quality.
(12). Auto power off when door open.
(13). Applicable industry: technology development, advertising design, art, ocational technical college Education & Training CNC and DIY enthusiasts.
Technical parameters
Turning diameter over bed(max)140mm
Travel across slide75mm
Chuck diameter80mm
Spindle speed100-2000r/min(control speed of G code)
Spindle through-hole11mm
Spindle mountMT2
Spindle motor power150W
X travel70mm
Z travel160mm
The max moving speed2000mm/min
The max feeding speed1000mm/min
Control systemKY 980Tc Turning CNC System
Tool position4
Tool dimension8×8mm
Tailstock taperMT1
Tailstock sleeve diameter20mm
Travel of tailstock25mm
Positioning accuracy0.02mm
Repeatability accuracy0.02mm
Power220VAC / 110VAC
Weight(NW/GW)50/65KG
Overall dimension750*450*450mm
Packing size850*470*470mm
