Product attributesProperty valueSelect Properties
| Manufacturer: | Texas Instruments |
|
| Product Category: | Op Amp - Op amp |
|
| RoHS: | Details |
|
| Installation style: | SMD/SMT |
|
| Package / Enclosure: | TSSOP-14 |
|
| Number of channels: | 4 Channel |
|
| Supply Voltage - Max: | 36 V |
|
| GBP-Gain Bandwidth Products: | 16 MHz |
|
| Output current per channel: | 50 mA |
|
| SR - Slew Rate : | 9 V/us |
|
| VOS - Input Bias Voltage : | 2 mV |
|
| Supply Voltage - Min: | 4.5 V |
|
| Minimum operating temperature: | - 40 C |
|
| Maximum operating temperature: | + 85 C |
|
| IB - Input bias: | 10 pA |
|
| Operating supply current: | 2 mA |
|
| Shut down: | No Shutdown |
|
| CMRR - Common Mode Rejection Ratio: | 110 dB |
|
| EN - Input voltage noise density: | 4.5 nV/sqrt Hz |
|
| Series: | OPA1679 |
|
| Encapsulation: | Reel |
|
| Encapsulation: | Cut Tape |
|
| Encapsulation: | MouseReel |
|
| 3dB bandwidth: | - |
|
| Amplifier Type: | Audio Operation Amplifier |
|
| Trademark: | Texas Instruments |
|
| In — Input noise current density: | 3 fA/sqrt Hz |
|
| IOS - Input Bias Current : | 10 pA |
|
| Maximum dual supply voltage: | +/- 18 V |
|
| Minimum dual supply voltage: | +/- 2.25 V |
|
| Humidity sensitivity: | Yes |
|
| Output Type: | Rail-to-Rail |
|
| Products: | Operational Amplifiers |
|
| Product Type: | Op Amps - Operational Amplifiers |
|
| Factory packing quantity: | 2000 |
|
| Subcategories: | Amplifier ICs |
|
| THD + Noise: | 0.0001 % |
|
| Unit weight: | 173 mg |
|
