a Complete Pb/MDF/HDF/OSB/Lsb/Plywood Production Line From China Factory

Product Description

A Complete PB/MDF/HDF/OSB/LSB Production Line from China Factory
WHAT IS THE DIFFERECE FOR PB vs OSB vs MDF?
Particleboard, OSB(oriented particle board) and MDF (Medium density board) are common wood-based artificial panels that differ in their manufacturing processes, properties and applications. Here are the differences and differences:
Particle board
- Manufacturing process: The wood or other wood fiber materials are crushed into fine particles, and hot pressed after adding an adhesive.
- Structure : uniform particle distribution, no specific direction.
- Density: Low, usually between 0.6-0.8 g/cm³.
- Strength: low, susceptible to moisture deformation.
- Surface treatment : Veneer or finish required.
- Application: Furniture, interior decoration, packaging, etc.
OSB (Oriented Strand Board)
- Manufacturing process : The wood is cut into thin slices, arranged in a directional manner and then hot pressed with adhesive.
- Structure : The sheets are arranged in a specific direction, usually the outer layer is lengthwise and the inner layer is transverse.
- Density: High, about 0.6-0.7g /cm³.
- Strength: high, good bending and tensile performance, moisture resistance is better than ordinary particle board.
- Surface treatment: Usually used directly, can also be veneer.
- Application : Building structure, roof, floor, wall panel, etc.
MDF (Medium Density Fiberboard)
- Manufacturing process: Wood or other plant fibers are crushed into fine fibers and hot-pressed after adding adhesives.
- Structure: Fiber distribution is uniform, no specific direction.
- Density: High, usually between 0.6-0.8 g/cm³.
- Strength: high, good bending and compressive performance, but poor moisture resistance.
- Surface treatment: Smooth surface, suitable for veneer, coating and engraving.
- Applications: furniture, door panels, decorative lines, audio equipment, etc.
WHAT IS THE PRODUCTION STEP?

	<1> Drum Chipper
	Inlet size	240*750mm(H*W)
	Blade quantity	2pcs
	Knife roll diameter	800mm
	Power	132kw
	<2> Ring Chipper
	Wood strands thickness	0.4-1.0mm
	Capacity	5000-8000kg/h
	Knife length	449mm
	Power	250kw
	<3> Triple Pass Drying Machine
	Cpacity	10000kg/h
	Original moisture	≤80%
	End moisture	2%
	Power	440kw
	<4> Vibrating screen
	Screening cloth	2
	Screening area	12 m2
	Screening capacity	70m3/h
	Power	11kw
	<5> Gluing
	Capacity	500m3 /per day
	<6> Forming machine
	Surface forming machine	2 sets
	Capacity	2 *45m3/h
	Core forming machine	1 sets
	Capacity	65m3/h
	Forming width	1300mm
	Forming thickness	30-120mm
	<7> Continuous press
	Convey speed	10-30m/min
	Working height	1250mm
	Belt width	1300mm /1500mm
	Power	75kw
	<8> Hot press
	Pressure	1200 ton
	Hot plate size	2650*1680*120mm
	Layers	12 /15 / 22 /24
	Heating medium	Oil
	Heating temperature	≤180ºC
	Closing time	10s
	<9> Sanding machine
	Max sanding width	1300mm/1700mm
	Sanding thickness	3-100mm
	Sanding belt size	1350*2800mm

For this production line, it can produce 100000m3 one year. And we can produced as your capacity requires

WHO WE ARE?

China professional factory of Particle board making machine /MDF making machine /OSB making machine. With advanced production technology and professional design technician teams, we can offer you the Suitble and Good wood based panel machinery for you
Welcome contact us for more information if you are interested

---
