Yz Automatic Reinforcement Mesh Weldine Production Line Stepless Adjustment

Product Description

Product Description

Dedicated in resistance welding machine for more than 20 years,Yizhou provide you one-stope welding machine professional solution
GWC-BT-3400 wire mesh welding line is designed for producing reinforcement mesh used in the field of railway, high way, building construction etc.
It has advantage of shifting mesh specifcation quickly and easy operation. It can meet the production requirement of small batch orders.
We have experienced R&D department to customize the welding machine according to your requirement.
Product Parameters

No.	Item	Specification
1	Wire Diameter	Φ5.0-12.0(mm)
2	Line Wire Spacing	75-400mm(infinitely adjustable manually)
3	Cross Wire Spacing	25-400mm(infinitely adjustable programming)
4	Max Mesh Width	3400mm
5	Max mesh length	6000mm/12000mm
6	Number of Electrodes	32
7	Welding Speed	50-80times/min
8	Rated Voltage	Three phase,380V,50Hz(according to requirement)
9	Rated Power	32*100KVA
10	Line Wire Feeding	Pre-cut bars by manual
11	Cross Wire Feeding	Pre-cut bars ,automatic blanking
12	Material	Low carbon round rebars or ribbed rebars
13	Mesh Pulling Way	CNC servo motor

Detailed Photos

Application
Contact Us
To know more information of machines,please contact us
Ms.Lancy

---
