Steel OTR Wheel Rim, OTR Wheel, Ming Wheel, Wheel Loader Rim, Earthmover Wheel Rim, Port Wheel

Product Description

Steel OTR Wheel Rim, OTR Wheel, Ming Wheel, Wheel Loader Rim, Earthmover Wheel Rim, Port wheel
To ensure product quality, the company established the ISO9001 quality system
configure the universal testing machine, air tightness testing machine, chemical detector and many other test equipment.
Product quality by customers.
Feature of our OTR Wheel
wheel for construction industries fully utilize high strength low alloy (HSLA) steel.
Heat treatment formed material is used for critical components on multi piece wheel.
Auto butt-welding is widely used on rim, ring and other circular parts;
All circumferential weld seams are inspected by nondestructive inspection to ensure zero defect.
Specifications
1. Multi Pieces: 3pcs, 5pcs
2. Tire: from 20-63 inch
3. Type: TL / TT
4. ISO Certificate
5. OEM Service.
6. Color: RAL1028, RAL9006, RAL9007, etc.
Customized colors are available by request to meet your needs.

Wheel Size	Recommend Tire Size	Specification (mm)
		A	B	C	D	E	F	G	H
25×10.00/1.5	14.00-25	254	635	38.1	574.6	173.3	82.7	546	27
25×11.25/2.0	16.00-25	285.8	635	50.8	574.6	185.7	82.7	546	27
25×13.00/2.5	18.00-25	330.2	635	63.5	574.6	211.4	82.7	546	27
25×14.00/1.5	17.5-25	356	635	38.1	574.6	224.1	82.7	546	27
25×15.00/3.0	21.00-25	381	635	76.2	574.6	236.5	82.7	546	27
25×17.00/2.0	20.5-25	431.8	635	50.8	574.6	262	82.7	546	27
25×19.50/2.5	23.5-25	495.3	635	63.5	574.6	293	82.7	546	27
33×13.00/2.5	18.00-33	330.2	838.2	63.5	574.6	211.4	82.7	749.2	27
