Welcome to visit

Donghang Plastic Tray and Lid Making Machine

US$26,000.00-30,000.00 1 Set (MOQ)

Basic Info.

Model NO.
DHBGJ-480L
Column number
Four Column
Molding Method
Hydraulic and Servo
Automatic Grade
Automatic
Forming Area
260X450
Raw Material
Pet
Shaping Mode
Die Molding
Application
Machinery & Hardware, Food & Beverage
Driven Type
Pneumatic
Computerized
Computerized
Transport Package
Wooden Packagintg
Specification
SGS
Trademark
DONGHANG
Origin
China
HS Code
8477409000
Production Capacity
50 Sets/Month

Product Description

Characteristic:
DHBGJ-480L It's a new type one that combines advantages of several types of main forming machines and also brings to more improvement and innovation.
With easy operation, calm running, convenient maintenance and stable function.
It can produce PVC, PS, PET etc. All kinds of covers.
it is two line of forming area, it works with servo motor and hydraulic, so the machine will be much more stable than others.
Functions and Features
1) Mold adopts clamping plate, easy to adjust and install.
2) Main motor adopts servo governor: Cutting frequency is adjustable of 10~28 Time/min. Moderate the suitable cutting frequency on the basis of stoke length and difficulty of forming.
3) Servo feeding corporate with squeeze motion. Smooth running, process synchronized, the maximum line control is 240mm, it means the dimensions can designed differently in this range.
4) Forming heating plate automatically close and open. It can power on delay, limits the waste of materials in once time. The heating power and temperature can be lowed by adopted contact heating of the plate. Through which it saved energy and enhance the stability of plastic piece.
Technical Data
Punching Frequency 20-35time/min
Adjustable scope of Travel 30-160mm
Max Forming Depth 50mm
Max. Forming Area 260mm*450mm
Air-compressor <0.2m 3 /min
Pressure 0.4-0.7MPa
Power 20Kw
Overall Dimension 4200*850*1700mm
Weight 2000Kg

If you are interested in our machine, please feel free and contact me.
Ruian Donghang Packing Machine Co.,Ltd
Add: Nantuozhan Industrial Zone Feiyun Town,
Ruian Zhejiang PR.China Post code:325207
Contacter: May Zheng


Web:http://cndonghang.en.made-in-china.com
