Small Combination Lathe and Milling Machine Mill Drill Combo Mini Lathe

US$868.00
1-2 Sets
US$848.00
3-4 Sets
US$808.00
5+ Sets

Basic Info.

Model NO.
CT125
Type
Horizontal Lathe
Processing Accessory
Chuck CNC Lathe
Guide Rail
Horizontal Guide Rail
Tool Holder
Single-tool Holder CNC Lathe
Power Source
Electric
Controlling Mode
Artificial
Automatic Grade
Manual
Setting Mode
Table
Precision
High Precision
Certification
GS, CE, RoHS, ISO 9001
Condition
New
Transport Package
Standard Wooden Packing
Specification
410*300*520mm
Trademark
CTMACH
Origin
China
HS Code
8458190000
Production Capacity
10000

Product Description

Turning-parameters
Max. swing over bed 125mm
Max. swing over tool post 60mm
Max.machining length 180mm
Spindle taper MT1
Spindle bore 9mm
Max. travel of tail-stock sleeve 18mm
Taper of tail-stock MT1
Metric thread/Grade 0.4~1.5mm/8
Inch thread/Grade 0.0028~0.0055T.P.I/8
Longitudinal feed/Grade 0.07~0.14mm/2
Spindle speed range/Grade 560~2500r/min(5)
Motor power 180w
Drilling and milling-parameters
Max.Drilling capacity 6mm
Table size 85x60mm
T-slots size 8mm
Spindle travel 40mm
Distance from spindle to column guide rail 125mm
Distance from spindle end to table surface 120~180mm
Spindle speeds 500~2500r/min(10)
Rotation angle of drilling and milling box head around the column 360°
Net weight/gross weight 22KG/25KG
Overall dimensions 520x300x410mm
Package Size 550x300x480mm
