Basic Info.
Certification
ISO9001: 2000, CE
Installed Electrical Power
75kw
Operating Mode
Electric Construction + Diesel-Powered Emergency
Control Mode
Wireless Remote Control
Operating Range (Width × Height)
26×15m
Chassis Form
Operating Chassi
Driving Mode
One-Way Driving
Driving and Steering Methods
Four-Wheel Drive, Front-Wheel Steering
Minimum Ground Clearance
420mm
Turning Radius
10m (Two Wheels)
Approach Angle/Departure Angle
16°/16°
Transport Package
Nothing
Specification
8340× 2700× 3250mm
Product Description
Product Description
The LHP40F The LHP40F wheeled wet spray manipulator represents a cutting-edge evolution in wet spray technology, drawing on the best domestic and international advancements. This next-generation machine boasts an optimized and upgraded structure, ensuring a remarkably low failure rate, high versatility in accessories and consumables, and reduced operating costs. With its extraordinary spray capacity, resistance to pipe blockages, minimal rebound, and reliable, consistent performance, the LHP40F enhances construction efficiency while significantly reducing concrete consumption.
Maximum spray volume reaches an impressive 40m³/h, offering excellent spraying efficiency and blockage-resistant pipes;
The innovative diesel-electric dual power system accelerates construction progress with seamless efficiency;
Designed with a compact footprint, the machine provides exceptional flexibility, making site entry and exit effortless;
High versatility in accessories and consumables ensures low operating costs and easy maintenance;
Equipped with dual quick-setting agent tanks, each with a 1.5 cubic meter capacity, the LHP40F is ideal for large section construction projects.
Product Parameters
| Transport dimensions (L × W × H) | 8340×2700×3250mm |
| Total weight | 16t |
| Engine power | 103kW |
| Installed electrical power | 75kW |
| Operating mode | Electric construction + diesel-powered emergency |
| Control mode | Wireless remote control |
| Operating voltage | 380V |
| Operating range (width × height) | 26×15m |
| Chassis form | Operating chassis |
| Driving mode | One-way driving |
| Driving and steering methods | Four-wheel drive, front-wheel steering |
| Minimum ground clearance | 420mm |
| Maximum grade | 29% |
| Turning radius | 10m (two wheels) |
| Maximum speed | 15km/h |
| Approach angle/departure angle | 16°/16° |
| Maximum spraying volume | 40m³/h |
| Maximum particle size for spray aggregate | 25mm |
| Hopper capacity | 0.3m³ |
| Capacity of quick-setting agent tank | 1.5m³ |
| Form of quick-setting agent pump | Squeeze pump |
| Discharge volume | / |
| Discharge pressure | / |
