Construction Equipment Mini 4X4 Wheel Loader7500kg Articulated Backhoe Loader Diesel Wheel Backhoe Excavator Loader

Product Description

Product Description
Products
Electric forklift
1. The operation and control of electric forklifts are simple and flexible, and the operating intensity of their operators is much lighter than that of internal combustion forklifts. The electric steering system, acceleration control system, hydraulic control system, and braking system are all controlled by electrical signals, greatly reducing the labor intensity of the operators. This is very helpful for improving their work efficiency and accuracy.
2. Electric forklifts are low-carbon and environmentally friendly. Generally, electric forklifts use batteries for operation, which will not have a negative impact on the environment. At the same time, the noise emitted by the engine of electric forklifts is very small, and the noise of new cars can be basically ignored.
3. From the perspective of enterprise costs, using electric forklifts to operate raw materials can significantly reduce the cost, which is also one of the important factors for many enterprises to choose electric forklifts. Enterprise cost control is an important component of enterprise development

parameter				uint	GWE75	GWE80	GWE90
Overall dimensions	overal length(transport)			mm	5870	6200	6500
	overall width			mm	1960	1960	2180
	()overall height(cabin)			mm	2875	2930	2930
	()overall height(walking)			mm	2875	2930	2930
Size parameters	tread		front	mm	1525	1525	1670
			rear	mm	1525	1525	1679
	wheelbase			mm	2350	2350	2400
	Platform clearance above ground			mm	1050	1050	1110
	Rotary radius of platform tail			mm	1800	2000	2000
	Chassis width			mm	1950	1950	2100
	Ground clearance of chassis			mm	345	345	320
	Body width			mm	1900	1900	2050
Operating range	Max excavation height			mm	6660	6750	7200
	Max unloading height			mm	4760	4890	5500
	Max depth of excavation			mm	2790	3190	3350
	Max vertical excavation depth			mm	2460	2725	2890
	Max excavation radius			mm	6090	6585	6900
	stop surface excavation distance			mm	5900	6340	6720
	Min radius of rotation			mm	2320	2550	2570
	Max height at min radius of gyration			mm	4780	5060	5500
	bulldozer lifts the max ground clearance			mm	300	310	300
	max depth to which a bulldozer can sink			mm	100	100	100
performance parameters	Self weight			kg	7200	7200	7600
	Standard bucket volume			m³	0.2~0.3	0.2~0.3	0.2-0.3
	(ISO)Bucket digging Force (ISO)			kN	32	32	35
	(ISO)Bucket rod digging force (ISO)			kN	22	22	26
	Walking speed		Forward gear	km/h	4.5	4.5	5
			Forward II gear	km/h	9	9	10
			Forward III gear	km/h	16	16	17
			Forward IV gear	km/h	26	26	28
			Forward V gear	km/h	33	33	32
			RBack R gear	km/h	4.5	4.5	5
	Climbing ability			°	30	30	30
	Rotary speed			rpm	10	10	10
engine	brand				xinchai	yuchai
	model				4D32YG30	YC4FA65-T300
	///4				Vertical/in-line/water cooled/four stroke
	displacement			L	2.98	3.16	3.16
	/Rated power/speed			kW/rpm	48/2300	50/2200
	Maximum torque			N.m/rpm	263/1600	243/1600	260/1400-1800
pump	type				gear pump	Plunger pump
	rate of flow			L/min	2x57	2x59.4
	Main relief valve pressure			MPa	21	21	21
	Fuel tank capacity			L	100	100	100
	Hydraulic tank capacity			L	118	118	118
Walk part	Tyre number			pcs	8	8	8
	model				7.50-16/16PR	8.25-16/16PR
	Front bridge swing Angle			°	8	8	8

---
