One Button Easy to Operate Paint Thickness Gauge

Product Description

EC-600 One Button Easy to Operate Paint Thickness Gauge
Specifications DESCRIPTION:
The series of EC-600 coating thickness gauges can be used to measure the thickness of non-conductive coatings on non-ferrous metals and non-magnetic insulating coatings on ferromagnetic metals (such as iron, nickel and cobalt, etc.). They are mainly used for non-destructive thickness measurement for the coatings of paint or galvanized layers on iron and stainless steel, paint or plastic film on aluminum and copper, etc.

FEATURES: Ruby probe Display the maximum, minimum,average and numbers of readings Display interface can check back 10 measurement values Single button operation Zero calibration supported Dot matrix display Automatic shut-down Battery protection

APPLICATION: Car paint thickness detection Shipbuilding Electroplating Metal anti-rust treatment Film thickness detection Hardware parts processing

Model	EC-600	EC-600S	EC-600E	EC-600SE
Probe type	Internal probe		External probe
Measuring principle	Fe: Magnetic induction; NFe: Eddy currents
Measuring range	0~2000um
Accuracy	±(3%+1um)	±(2%+1um)	±(3%+1um)	±(2%+1um)
Resolution	0.1um(0~100um); 1um(>100um)
Unit	um, mm, mils
Calibration	Zero calibration
Storage		10*13*10 measurement data		10*13*10 measurement data
Probe trigger mode	Mechanical trigger, trigger force: 0.5~1.2N
Maximum measuring rate	2 readings/s
Display	128*48 dot matrix LCD display, with backlight
Bluetooth & APP	N	Y	N	Y
Operation environment	Temperature: -10~+50ºC Humidity: 20~90%RH (Non-condensing)
Storage environment	Temperature: -20~+60ºC Humidity: 20~90%RH (Non-condensing)
Power supply	Two pcs 1.5V AAA alkaline battery; Two pcs 1.2V AAA rechargeable battery
Protection class	IP40
Size	103*62*27mm		Housing: 103*62*27mm
			Cable: Φ3.5*1000mm
			Probe: Φ17*67mm
Case material	ABS		Housing: ABS
			Probe: Stainless Steel
Weight	About 57g (No battery)		About 112g (No battery)
Standard compliance	CE,ROHS,ISO 2178,2360,GB/T 4956-2003,4957-2003,JJG-818-2005
Warranty	12 months

Product Display
Packing List
Company Profile
FAQ
Q. Do you make custom products?
A. Yes, we offer OEM/ODM solutions for our clients.

Q. How long is your lead time for samples?
A. 5-7 days. For bulk orders, 10-30 days depending on the quantity.

Q. What is your terms of payment?
A. 100% for small orders. 30% in advance as deposit and 70% balance before the delivery.

Q. How can we pay?
A. You can pay via T/T, PayPal and Western Union.

---
